| Item | Part No. | Part Name | Qty | Serial No. |
| 22-580332-00 | GLOVE BUCKET ASS'Y,0.8M3 CM | (1001)- | ||
| 22-580385-00 | BODY ASS'Y | (1001)- | ||
| 1 | 22-595648-21 | BODY | (1001)- | |
| 2 | 22-595556-01 | BUSHING | (1001)- | |
| 3 | 22-595552-01 | AXLE | (1001)- | |
| 22-580386-00 | ROD ASS'Y | (1001)- | ||
| 4 | 22-595649-01 | ROD | (1001)- | |
| 5 | 22-595554-01 | BUSHING | (1001)- | |
| 6 | 22-595647-01 | SCREW | (1001)- | |
| 7 | 22-595650-01 | AXLE | (1001)- | |
| 22-580387-00 | FRAME ASS'Y | (1001)- | ||
| 8 | 22-595651-01 | FRAME | (1001)- | |
| 9 | 22-595556-01 | BUSHING | (1001)- | |
| 22-580333-01 | SHEAVE ASS'Y | (1001)- | ||
| 10 | \6\ | SHEAVE | (1001)- | |
| 11 | 22-595562-01 | BUSHING | (1001)- | |
| 12 | 22-595564-01 | AXLE | (1001)- | |
| 13 | 22-595652-01 | AXLE | (1001)- | |
| 14 | 22-595566-21 | END | (1001)- | |
| 15 | 22-595653-01 | FRAME | (1001)- | |
| 16 | 22-595570-01 | GUIDE | (1001)- | |
| 17 | 22-595571-01 | BRACKET | (1001)- | |
| 18 | 22-595568-01 | PIN | (1001)- | |
| 19 | 22-595569-01 | PIN | (1001)- | |
| 20 | 22-595572-01 | HANGER | (1001)- | |
| 21 | 22-595573-01 | PIN | (1001)- | |
| 22 | 22-595574-01 | SOCKET | (1001)- | |
| 23 | 22-595646-01 | WEDGE | (1001)- | |
| 24 | 22-595576-01 | CHAIN,3M | (1001)- | |
| 25 | 22-595578-01 | SHACKLE | (1001)- | |
| 26 | 22-595654-01 | FITTING | (1001)- | |
| 27 | 01001-31600 | BOLT | (1001)- | |
| 28 | 22-595557-01 | BOLT | (1001)- | |
| 29 | 01001-31620 | BOLT | (1001)- | |
| 30 | 01900-10450 | NUT | (1001)- | |
| 31 | 01500-31613 | NUT | (1001)- | |
| 32 | 01500-32218 | NUT | (1001)- | |
| 33 | 01970-11020 | NUT | (1001)- | |
| 34 | 01602-01338 | WASHER | (1001)- | |
| 35 | 01640-02540 | WASHER | (1001)- | |
| 36 | 04050-05055 | PIN | (1001)- | |
| 37 | 22-595560-01 | AXLE | (1001)- |
