| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 21P-62-K3160 | TUBE | K30001- | |
| 2 | 21P-62-K3171 | TUBE | K34001- | |
| 21P-62-K3170 | TUBE | K30001-K34000 | ||
| 3 | 203-70-53381 | PLATE | K30001- | |
| 4 | 20G-70-K2330 | CUSHION | K30001- | |
| 5 | 203-70-53391 | PLATE | K32001- | |
| 203-973-5650 | CLAMP | K30001-K31999 | ||
| 6 | 203-973-5680 | SEAT | K30001- | |
| 7 | 203-973-5660 | CLAMP | K30001- | |
| 8 | 203-973-5690 | SEAT | K30001- | |
| 9 | 01643-31032 | WASHER | K30001- | |
| 10 | 01010-81060 | BOLT | K30001- | |
| 11 | 01010-81075 | BOLT | K30001- | |
| 12 | 203-973-5710 | SEAT | K30001- | |
| 13 | 01010-81025 | BOLT | K30001- | |
| 14 | 01010-81035 | BOLT | K30001- | |
| 15 | 01010-81075 | BOLT | K30001- | |
| 16 | 203-62-58810 | CUSHION | K30001- |
