| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 6263-11-6760 | BRACKET | ||
| 2 | 01010-80865 | BOLT | ||
| 3 | 01643-30823 | WASHER | ||
| 4 | 01010-80855 | BOLT | ||
| 5 | 01643-30823 | WASHER | ||
| 6 | 6263-81-8420 | BRACKET | ||
| 7 | 01010-80820 | BOLT | ||
| 8 | 01643-30823 | WASHER | ||
| 9 | 6263-61-9680 | BRACKET | ||
| 10 | 6262-11-5980 | BOLT | ||
| 11 | 6263-61-9690 | COVER | ||
| 12 | 01010-81025 | BOLT | ||
| 13 | 01643-31032 | WASHER | ||
| 14 | 6263-71-7570 | BRACKET | ||
| 15 | 01010-80860 | BOLT | ||
| 16 | 01643-30823 | WASHER | ||
| 17 | 01010-81025 | BOLT | ||
| 18 | 01643-31032 | WASHER | ||
| 19 | 6263-11-6760 | BRACKET | ||
| 20 | 600-816-2620 | SENSOR, NOX | ||
| 21 | 01010-80625 | BOLT | ||
| 22 | 01643-30623 | WASHER | ||
| 23 | 01010-81025 | BOLT | ||
| 24 | 01643-31032 | WASHER | ||
| 25 | 6263-11-6770 | BRACKET | ||
| 26 | 01010-81050 | BOLT | ||
| 27 | 01643-31032 | WASHER | ||
| 28 | 6263-11-6750 | BRACKET | ||
| 29 | 01010-81020 | BOLT | ||
| 30 | 01643-31032 | WASHER | ||
| 31 | 6253-81-4410 | CLIP | ||
| 32 | 01010-81020 | BOLT | ||
| 33 | 01643-31032 | WASHER | ||
| 34 | 6262-11-8430 | COVER |
