| Item | Part No. | Part Name | Qty | Serial No. |
| 385-10246791 | PEDAL ASS'Y,ACCELERATOR | 10439- | ||
| 385-10230041 | PEDAL ASS'Y,ACCELERATOR | 10331-10438 | ||
| 385-10117461 | PEDAL ASS'Y,ACCELERATOR | 10001-10330 | ||
| 1 | 385-10246801 | PEDAL | 10439- | |
| 385-10230051 | PEDAL | 10331-10438 | ||
| 385-10123591 | PEDAL | 10001-10330 | ||
| 2 | 381-975746-1 | HINGE | 10001- | |
| 3 | 382-370686-1 | BUSHING | 10001- | |
| 4 | 380-178171-1 | PIN | 10001- | |
| 5 | 380-143606-1 | PIN | 10001- | |
| 6 | 01010-50625 | BOLT | 10001- | |
| 7 | 01643-30623 | WASHER | 10001- | |
| 8 | 01580-10605 | NUT | 10001- | |
| 9 | 385-10130121 | END | 10001-10330 | |
| 10 | 01010-50625 | BOLT | 10001-10330 | |
| 10A | 384-0138083 | PIN | 10331- | |
| 11 | 01643-30623 | WASHER | 10001-10330 | |
| 11A | 384-0103361 | PIN | 10331- | |
| 12 | 385-10163691 | NUT | .-10330 | |
| \0\01580-10605 | NUT | 10001-. | ||
| 13 | 385-10117481 | ROD | 10001-10330 | |
| 13A | 385-10230071 | BAR | 10331- | |
| 14 | 01580-10605 | NUT | 10001-10330 | |
| 15 | 385-10130311 | BOLT | 10001- | |
| 16 | 01580-11008 | NUT | 10001- | |
| 17 | 385-10230081 | SUPPORT | 10331- | |
| 385-10153661 | SUPPORT | 10001-10330 | ||
| 18 | 385-10153681 | BELLCRANK ASS'Y | 10001-10330 | |
| 19 | 380-885064-1 | BUSHING | 10001-10330 | |
| 20 | 01010-50625 | BOLT | 10001- | |
| 21 | 01643-30623 | WASHER | 10001- | |
| 22 | 01580-10605 | NUT | 10001- | |
| 23 | 380-119059-1 | SPRING | 10001- | |
| 24 | 385-10117571 | RETAINER | 10001-10330 | |
| 25 | 385-10360861 | JOINT,ROD | 10691- | |
| 385-10130131 | END,ROD | 10001-10690 | ||
| 26 | 01010-50830 | BOLT | 10001-10690 | |
| 27 | 01643-30823 | WASHER | 10001-10690 | |
| 28 | 385-10163701 | NUT | .-10690 | |
| \0\01580-10806 | NUT | 10001-. | ||
| 29 | 385-10161861 | ROD | 10001- | |
| 30 | 01580-10806 | NUT | 10001- | |
| 31 | 385-10360871 | BELLCRANK ASS'Y | 10691- | |
| 385-10151021 | BELLCRANK ASS'Y | 10001-10690 | ||
| 32 | 380-885064-1 | BUSHING | 10001- | |
| 33 | 382-025534-1 | WASHER | 10001- | |
| 34 | 385-10204241 | SUPPORT | 10247- | |
| 385-10151001 | SUPPORT | 10001-10246 | ||
| 35 | 384-0103373 | PIN | 10001- | |
| 36 | 01010-51020 | BOLT | 10001- | |
| 37 | 01643-31032 | WASHER | 10001- | |
| 38 | 385-10151061 | ROD | 10001- | |
| 39 | 385-10130121 | END,ROD | 10001- | |
| 40 | 01580-10605 | NUT | 10001- | |
| 41 | 01010-50625 | BOLT | 10001- | |
| 42 | 01643-30623 | WASHER | 10001- | |
| 43 | 385-10163691 | NUT | .- | |
| \0\01580-10605 | NUT | 10001-. | ||
| 44 | 385-10230061 | BELLCRANK | 10331- |
