| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07238-00315 | CONNECTOR | 1501- | |
| 2 | 07108-20333 | HOSE | 1543- | |
| 3 | 561-43-41260 | ELBOW | 1501- | |
| 4 | 561-43-41280 | ELBOW | 1501- | |
| 5 | 07261-21448 | HOSE | 1501- | |
| 6 | 281-04-15570 | TUBE | 1501- | |
| 7 | 07281-00289 | CLAMP | 1501- | |
| 8 | 566-03-12620 | CLAMP | 1543- | |
| 9 | 566-01-12350 | SPACER | 1543- | |
| 10 | 01010-51265 | BOLT | 1543- | |
| 11 | (01602-21236) | WASHER | 1543- | |
| 12 | 01010-51020 | BOLT | 1501- | |
| 13 | 01602-21030 | WASHER | 1501- | |
| 14 | 01010-51225 | BOLT | 1543- | |
| 15 | 01602-21236 | WASHER | 1501- | |
| 16 | 08036-02514 | CLIP | 1501- | |
| 17 | 566-16-11560 | CLIP | 1501- | |
| 18 | 01010-51020 | BOLT | 1501- | |
| 19 | 01602-21030 | WASHER | 1501- | |
| 20 | 01580-11008 | NUT | 1501- |
