| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | HA7568 | HOSE | ||
| 2 | HA7566 | HOSE | ||
| 3 | VN9913 | CLAMP | ||
| 4 | VN2997 | WELD STUD - 3/8" - 16NC X 1 1/4" | ||
| 5 | C1547 | FLAT WASHER - 3/8" | ||
| 6 | C0312 | LOCKWASHER - 3/8" | ||
| 7 | C1521 | NUT - 3/8" - 16NC | ||
| 8 | EG8707 | MOUNTING | ||
| 9 | PB9288 | COMPRESSOR | ||
| 10 | MM0032 | CAPSCREW - M12 X 1.75 X 30 | ||
| 11 | MM0705 | FLAT WASHER - M12 (HARDENED) | ||
| 12 | MM0026 | CAPSCREW - M8 X 1.25 X 25 | ||
| 13 | MM0470 | LOCKWASHER - M8 | ||
| 14 | MM0045 | CAPSCREW - M12 X 1.75 X 40 | ||
| 15 | MM0472 | LOCKWASHER - M12 | ||
| 16 | MM0462 | FLAT WASHER - M12 | ||
| 17 | MM0179 | NUT - M12 X 1.75 | ||
| 18 | EG8702 | GUARD | ||
| 19 | EG8710 | BRACKET, REAR | ||
| 20 | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | ||
| 21 | WA0720 | FLAT WASHER - 3/8" | ||
| 22 | PB8730 | HOLD DOWN, ADJUSTABLE | ||
| 23 | MM0047 | CAPSCREW - M10 X 1.50 X 30 | ||
| 24 | MM0704 | FLAT WASHER - M10 | ||
| 25 | PB9152 | FITTING, A/C COMPRESSOR | ||
| 26 | PB9942 | FITTING, A/C COMPRESSOR | ||
| 27 | EG8711 | LINK | ||
| 28 | ED7061 | BRACKET, REAR ADJUSTING | ||
| 29 | EG8720 | GUARD | ||
| 30 | ED7063 | BRACKET, FRONT MOUNTING | ||
| 31 | MM0039 | CAPSCREW - M12 X 1.75 X 35 | ||
| 32 | PC0304 | V-BELT | ||
| 33 | WA1733 | O-RING | ||
| 34 | WA1732 | O-RING | ||
| 35 | ED7060 | BRACKET, FRONT ADJUSTING |
