| Item | Part No. | Part Name | Qty | Serial No. |
| 195-Z11-6102 | AIR CONDITIONER A. | 16233-16490 | ||
| 195-Z11-6101 | AIR CONDITIONER A. | 16001-16232 | ||
| 1 | (195-Z11-5301) | COMPRESSOR ASS'Y | 16001-16490 | |
| 2 | 195-Z11-6351 | HOSE | 16001-16490 | |
| 3 | ND949140-2690 | O-RING | 16001-16490 | |
| 4 | 195-Z11-6391 | HOSE | 16233-16490 | |
| 195-Z11-6390 | HOSE | 16001-16232 | ||
| 5 | ND949140-3220 | O-RING | 16001-16490 | |
| 6 | 423-T43-1410 | TANK | 16233-16490 | |
| \3\198-911-4610 | TANK,RECIEVER | 16001-16232 | ||
| (423-T43-1410{195-Z11-6391¤} | ||||
| 195-Z11-6411) | ||||
| 7 | 198-911-4590 | HOLDER | 16001-16490 | |
| 8 | 195-Z11-6411 | HOSE | 16233-16490 | |
| 195-Z11-6410 | HOSE | 16001-16232 | ||
| 9 | ND949140-3220 | O-RING | 16001-16490 | |
| 10 | 195-Z11-6480 | HOSE | 16001-16490 | |
| 11 | ND949140-2080 | O-RING | 16001-16490 | |
| 12 | 195-Z11-6420 | CONNECTOR ASS'Y | 16001-16490 | |
| 13 | 195-Z11-6430 | CONNECTOR ASS'Y | 16001-16490 | |
| 14 | 195-Z11-6460 | CONNECTOR ASS'Y | 16001-16490 | |
| 15 | 195-Z11-6470 | CONNECTOR ASS'Y | 16001-16490 | |
| 16 | 195-Z11-6450 | HOSE | 16001-16490 | |
| 17 | ND949140-2080 | O-RING | 16001-16490 | |
| 18 | 195-Z11-6440 | HOSE | 16001-16490 | |
| 19 | ND949140-3220 | O-RING | 16001-16490 | |
| 20 | 145-Z79-5610 | JOINT | 16001-@ | |
| 21 | 425-963-1190 | HOSE | 16233-@ | |
| \0\195-Z11-7260 | HOSE | 16001-16232 | ||
| 22 | 195-Z11-7270 | CLAMP | 16001-@ | |
| 23 | 175-979-7260 | CLIP | 16001-16490 | |
| 24 | 01010-51220 | BOLT | 16001-@ | |
| 25 | 01643-31232 | WASHER | 16001-@ | |
| 26 | 198-06-41230 | BRACKET | 16001-@ | |
| 27 | 01010-51225 | BOLT | 16001-@ | |
| 28 | 01643-31232 | WASHER | 16001-@ | |
| 29 | 175-79-82710 | CLIP | 16001-16490 | |
| 30 | 01010-51220 | BOLT | 16001-@ | |
| 31 | 01643-31232 | WASHER | 16001-@ | |
| 32 | 01010-50820 | BOLT | 16001-@ | |
| 33 | 01602-20825 | WASHER,SPRING | 16001-@ | |
| 34 | 04434-52512 | CLIP | 16022-16490 | |
| 04434-52511 | CLIP | 16001-16021 | ||
| 35 | 01010-51020 | BOLT | 16001-@ | |
| 36 | 01643-31032 | WASHER | 16001-@ | |
| 37 | 154-Z11-5620 | BRACKET | 16001-16490 | |
| 38 | 01010-50865 | BOLT | 16001-16490 | |
| 39 | 01643-30823 | WASHER | 16001-16490 | |
| 40 | 195-Z11-5190 | BRACKET | 16001-@ | |
| 41 | 01011-51080 | BOLT | 16001-@ | |
| 42 | 01643-31032 | WASHER | 16001-@ | |
| 43 | 195-Z11-7250 | CLIP | 16001-@ | |
| 44 | 01010-51225 | BOLT | 16001-@ | |
| 45 | 01643-31232 | WASHER | 16001-@ | |
| 46 | 154-06-41390 | BRACKET | 16001-@ | |
| 47 | 01010-51275 | BOLT | 16001-@ | |
| 48 | 01643-31232 | WASHER | 16001-@ | |
| 49 | 195-979-3530 | CLIP | 16001-16490 | |
| 50 | 01010-51225 | BOLT | 16001-@ | |
| 51 | 01643-31232 | WASHER | 16001-@ | |
| 52 | 195-Z11-7240 | PLATE | 16001-@ | |
| 53 | 01010-50825 | BOLT | 16001-@ | |
| 54 | 01643-30823 | WASHER | 16001-@ | |
| 55 | 195-Z11-7220 | CLIP | 16001-@ | |
| 56 | 01010-51050 | BOLT | 16001-@ | |
| 57 | 01602-21030 | WASHER,SPRING | 16001-@ | |
| 58 | 08034-00519 | BAND | 16022-@ |
