| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 09488-20520 | HOSE | 1101- | |
| 2 | 566-07-41491 | JOINT | 1101- | |
| 3 | 01010-51030 | BOLT | 1101- | |
| 4 | 01643-31032 | WASHER | 1101- | |
| 5 | 01580-11008 | NUT | 1101- | |
| 6 | 566-07-41730 | UNION | 1101- | |
| 7 | 566-07-41740 | NUT | 1101- | |
| 8 | 566-07-41510 | HOSE | 1101- | |
| 9 | 566-07-41480 | HOSE | 1101- | |
| 10 | 566-07-11450 | TAPE | 1101- | |
| 11 | 566-07-41710 | UNION | 1101- | |
| 12 | 566-07-41720 | NUT | 1101- | |
| 13 | 561-07-38110 | HOSE | 1101- | |
| 14 | 566-07-41370 | INSULATOR | 1101- | |
| 15 | 198-03-16640 | CLIP | 1101- | |
| 16 | 01010-51016 | BOLT | 1101- | |
| 17 | 01643-31032 | WASHER | 1101- | |
| 18 | 08034-00536 | BAND | 1101- | |
| 19 | 567-07-15221 | NIPPLE | 1101- | |
| 20 | 09483-00507 | HOSE | 1101- | |
| 21 | 565-95-17230 | CLAMP | 1101- | |
| 22 | 287-82-11640 | NIPPLE | 1101- | |
| 23 | 09483-00524 | HOSE | 1101- | |
| 24 | 565-95-17230 | CLAMP | 1101- | |
| 25 | 09484-00550 | CONNECTOR | 1101- | |
| 26 | 09483-20550 | HOSE | 1101- | |
| 27 | 09483-00537 | HOSE | 1101- | |
| 28 | 565-95-17230 | CLAMP | 1101- | |
| 29 | 08037-02512 | GROMMET | 1101- | |
| 30 | 08037-03614 | GROMMET | 1101- | |
| 31 | 08037-02512 | GROMMET | 1101- |
