| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 428-S62-1130 | HOSE | 10112- | |
| 2 | 428-S62-1170 | HOSE | 10112- | |
| 3 | 01435-00630 | BOLT | 10112- | |
| 4 | 428-S62-1180 | HOSE | 10112- | |
| 5 | 428-S62-1140 | HOSE | 10112- | |
| 6 | 428-S62-1150 | HOSE | 10112- | |
| 7 | 01435-00625 | BOLT | 10112- | |
| 8 | 01643-30623 | WASHER | 10112- | |
| 9 | 419-S62-2250 | JOINT | 10112- | |
| 10 | 428-S62-1160 | HOSE | 10112- | |
| 11 | 04435-52212 | CLIP | 10112- | |
| 12 | 01435-01016 | BOLT | 10112- | |
| 13 | 04434-52212 | CLIP | 10112- | |
| 14 | 01435-01016 | BOLT | 10112- | |
| 15 | 04435-51910 | CLIP | 10112- | |
| 16 | 01435-01016 | BOLT | 10112- | |
| 17 | 08036-01014 | CLIP | 10001- | |
| 18 | 01435-01016 | BOLT | 10112- | |
| 19 | 426-S62-1220 | WIRE ASS'Y | 10112- | |
| 08020-10000 | DIODE | 10112- | ||
| 20 | 01010-80816 | BOLT | 10001- | |
| 21 | 01643-30823 | WASHER | 10001- | |
| 22 | 08052-01311 | CLIP | 10001- | |
| 23 | 01220-40608 | SCREW | 10001- | |
| 24 | 01641-20608 | WASHER | 10001- | |
| 25 | 20Y-979-3120 | TANK | 10112- | |
| 26 | 428-S62-1110 | BRACKET | 10112- | |
| 27 | 07283-26155 | CLIP | 10112- | |
| 28 | 01597-01009 | NUT | 10112- | |
| 29 | 01643-31032 | WASHER | 10112- | |
| 30 | 01435-00820 | BOLT | 10112- | |
| 31 | 04434-51510 | CLIP | 10112- | |
| 32 | 04434-52212 | CLIP | 10112- | |
| 33 | 01435-01016 | BOLT | 10112- | |
| 34 | 04435-52212 | CLIP | 10112- | |
| 35 | 07287-01420 | HOSE | 10112- | |
| 36 | 07281-00259 | CLAMP | 10112- | |
| 37 | 04434-51810 | CLIP | 10112- | |
| 38 | 01435-01016 | BOLT | 10112- | |
| 39 | (421-07-21530) | CONDENSER ASS'Y | 10112- | |
| 40 | 428-T46-1110 | PLATE | 10001- | |
| 41 | 01435-01220 | BOLT | 10001- |
