| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | AHHA8701 | Hose | 80138- | |
| 2 | 566-61-14420 | Spiral Tube | 80138- | |
| 3 | AHWA1732 | O-ring | 80138- | |
| 4 | 04434-52711 | Clip | 80138- | |
| 5 | 07095-20418 | Cushion | 80138- | |
| 6 | AHWB1303 | Clamp | 80138- | |
| 7 | 58B-07-20000 | Adapter | 80233- | |
| 7 | AHPC2276 | Adapter | 80138-80232 | |
| 8 | AHHA8788 | Hose | 80138- | |
| 9 | AHWB1027 | O-ring | 80138- | |
| 10 | 6150-81-6920 | Spacer | 80159- | |
| 11 | 04434-53211 | Clip | 80138- | |
| 12 | 07095-20523 | Cushion | 80138- | |
| 13 | 01010-81020 | Bolt | 80159- | |
| 14 | 01643-31032 | Washer | 80159- | |
| 15 | 01643-31232 | Washer | 80138- | |
| 16 | AHHA8103 | Hose | 80138- | |
| 17 | AHWB1027 | O-ring | 80138- | |
| 18 | AHWA1733 | O-ring | 80138- | |
| 19 | 04434-53211 | Clip | 80138- | |
| 20 | 07095-20523 | Cushion | 80138- | |
| 21 | AHHA8104 | Hose | 80138- | |
| 22 | AHWA1731 | O-ring | 80138- | |
| 23 | 04434-52110 | Clip | 80138- | |
| 24 | 07095-20314 | Cushion | 80138- | |
| 25 | AHHA8105 | Hose | 80138- | |
| 26 | AHWA1731 | O-ring | 80138- | |
| 27 | 04434-52110 | Clip | 80138- | |
| 28 | 07095-20314 | Cushion | 80138- | |
| 29 | 01010-81020 | Bolt | 80138- | |
| 30 | 01643-31032 | Washer | 80138- | |
| 31 | 562-07-31111 | Cover | 80138- | |
| 32 | 01010-81020 | Bolt | 80138- | |
| 33 | 01643-31032 | Washer | 80138- | |
| 34 | 562-07-31120 | Cover | 80138- | |
| 35 | 01010-81020 | Bolt | 80138- | |
| 36 | 01643-31032 | Washer | 80138- | |
| 37 | 01010-81060 | Bolt | 80159- | |
| 38 | 01643-31032 | Washer | 80159- | |
| 39 | 04434-52110 | Clip | 80159- | |
| 40 | 07095-20314 | Cushion | 80159- | |
| 41 | 04434-52112 | Clip | 80159- | |
| 42 | 07095-20314 | Cushion | 80159- | |
| 43 | (AHXB7317) | Air Compressor Assembly | - | |
| 44 | (AHPC2268) | Receiver Drier | - | |
| 45 | (AHPC1830) | Accumulator | - |
