| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | BW022465 | BRACKET | 61316-61999 | |
| 1 | BW022163 | BRACKET | 60636-61315 | |
| 2 | BW060476 | BOLT | 60636-61999 | |
| 3 | BW060468 | BOLT | 60636-61999 | |
| 4 | BW063348 | WASHER | 60636-61999 | |
| 5 | BW057647 | CLUTCH ASS'Y | 61316-61999 | |
| 5 | BW057445 | COMPRESSOR | 60636-61315 | |
| 6 | BW060584 | BOLT | 60636-61999 | |
| 7 | BW063348 | WASHER | 60636-61999 | |
| 8 | \6\ | SHIM | 60636-61999 | |
| 9 | BW063039 | NUT | 60636-61999 | |
| 10 | BW251245 | ROD | 61316-61999 | |
| 10 | BW045713 | ROD | 60636-61315 | |
| 11 | BW061489 | BOLT | 60636-61999 | |
| 12 | BW063348 | WASHER | 60636-61999 | |
| 13 | BW063039 | NUT | 60636-61999 | |
| 14 | BW151560 | BRACKET | 61316-61999 | |
| 14 | BW045709 | BRACKET | 60636-61315 | |
| 15 | BW061490 | BOLT | 60636-61999 | |
| 16 | BW063348 | WASHER | 60636-61999 | |
| 17 | BW063039 | NUT | 60636-61999 | |
| 18 | BW063102 | NUT | 60636-61999 | |
| 19 | BW057642 | BELT | 61316-61999 | |
| 19 | BW057444 | BELT | 60636-61315 | |
| 20 | BW034365 | HOSE | 61393-61999 | |
| 21 | BW057346 | O-RING | 61393-61999 | |
| 22 | BW057668 | CONNECTOR | 61393-61999 | |
| 23 | BW057346 | O-RING | 61393-61999 | |
| 24 | BW046145 | BRACKET | 61393-61999 | |
| 25 | BW065009 | CLAMP | 60636-61999 | |
| 26 | BW061461 | BOLT | 60636-61999 | |
| 27 | BW063036 | NUT | 60636-61999 | |
| 28 | BW034366 | HOSE | 61393-61999 | |
| 28 | BW057341 | HOSE | 60636-61392 | |
| 29 | BW057346 | O-RING | 60636-61999 | |
| 30 | BW033536 | BRACKET | 60636-61999 | |
| 31 | BW065009 | CLAMP | 60636-61999 | |
| 32 | BW061461 | BOLT | 60636-61999 | |
| 33 | BW063036 | NUT | 60636-61999 | |
| 34 | BW057471 | CONDENSER | 60636-61999 | |
| 35 | BW061476 | BOLT | 60636-61999 | |
| 36 | BW063038 | NUT | 60636-61999 | |
| 37 | BW022001 | RAIL,LOWER | 60636-61999 | |
| 38 | BW022002 | RAIL,UPPER | 60636-61999 | |
| 39 | BW060472 | BOLT | 60636-61999 | |
| 40 | BW063348 | WASHER | 60636-61999 | |
| 43 | (BW251234) | RADIATOR ASS'Y,(SEE FIG.1101) | 60636-61999 | |
| 44 | BW057342 | HOSE | 60636-61999 | |
| 45 | BW057347 | O-RING | 60636-61999 | |
| 46 | BW065007 | CLAMP | 60636-61999 | |
| 47 | BW057590 | TEE | 60636-61999 | |
| 48 | \6\ | O-RING | 60636-61999 | |
| 49 | BW057384 | SENSOR,GAS PRESSURE (A/C) | 60636-61999 | |
| 50 | BW057347 | O-RING | 60636-61999 | |
| 51 | BW057338 | RESERVOIR,FLUID | 60636-61999 | |
| 52 | BW032604 | BRACKET | 60636-61999 | |
| 53 | BW061462 | BOLT | 60636-61999 | |
| 54 | BW063036 | NUT | 60636-61999 | |
| 55 | BW057643 | HOSE | 61316-61999 | |
| 55 | BW057343 | HOSE | 60636-61315 | |
| 56 | BW057347 | O-RING | 60636-61999 | |
| 57 | BW065007 | CLAMP | 60636-61999 | |
| 58 | BW065012 | CLAMP | 60636-61999 | |
| 59 | BW065009 | CLAMP | 60636-61999 | |
| 60 | BW061461 | BOLT | 60636-61999 | |
| 61 | BW063036 | NUT | 60636-61999 | |
| 62 | BW065007 | CLAMP | 60636-61999 | |
| 63 | BW065009 | CLAMP | 60636-61999 | |
| 64 | BW061461 | BOLT | 60636-61999 | |
| 66 | BW057614 | EVAPORATOR | 60636-61999 | |
| 66 | BW057328 | COMPOUND | 60636-61999 | |
| 68 | BW057644 | HOSE | 61316-61999 | |
| 68 | BW057344 | HOSE | 60636-61315 | |
| 69 | BW057345 | O-RING | 60636-61999 | |
| 70 | BW065009 | CLAMP | 60636-61999 |
