| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07822-00820 | TUBE | 1501- | |
| 2 | 07822-00825 | TUBE | 1501- | |
| 411-44-11440 | ELBOW | 1501- | ||
| 3 | 285-35-11680 | ELBOW | 1501- | |
| 4 | 281-35-19430 | SLEEVE | 1501- | |
| 5 | 281-35-19930 | NUT | 1501- | |
| 6 | 561-35-32330 | BRACKET | 1501- | |
| 7 | 07042-00415 | PLUG | 1501- | |
| 8 | 01010-50825 | BOLT | 1501- | |
| 9 | 01602-20825 | WASHER | 1501- | |
| 10 | (567-35-11201) | RELAY VALVE ASS'Y | 1501- | |
| 11 | 07822-00602 | TUBE | 1501- | |
| 285-35-12550 | TEE | 1501- | ||
| 12 | 285-35-12650 | TEE | 1501- | |
| 13 | 281-35-19420 | SLEEVE | 1501- | |
| 14 | 281-35-19920 | NUT | 1501- | |
| 15 | 07834-00613 | ELBOW | 1501- | |
| 16 | 07831-00612 | SLEEVE | 1501- | |
| 17 | 07832-00614 | NUT | 1501- | |
| 18 | 411-44-15580 | JOINT | 1501- | |
| 281-35-19540 | ELBOW | 1501- | ||
| 19 | 281-35-19960 | ELBOW | 1501- | |
| 20 | 281-35-19430 | SLEEVE | 1501- | |
| 21 | 281-35-19930 | NUT | 1501- | |
| 22 | 07822-00850 | TUBE | 1501- | |
| 23 | 07822-00815 | TUBE | 1501- | |
| 24 | 07834-00817 | ELBOW | 1501- | |
| 25 | 07836-00817 | CONNECTOR | 1501- | |
| 26 | 07831-00813 | SLEEVE | 1501- | |
| 27 | 07832-00817 | NUT | 1501- | |
| 28 | (566-35-11205) | BRAKE CHAMBER ASS'Y | 1501- | |
| 29 | 01010-51240 | BOLT | 1501- | |
| 30 | 01602-21236 | WASHER | 1501- | |
| 31 | 281-01-13180 | CLIP | 1501- | |
| 32 | 08036-02514 | CLIP | 1501- | |
| 33 | 01010-51016 | BOLT | 1501- | |
| 34 | 01602-21030 | WASHER | 1501- |
