| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07822-00841 | TUBE | 1002- | |
| 281-35-19350 | ELBOW | 1002- | ||
| 2 | 07834-00817 | ELBOW | 1101- | |
| 2 | \0\285-35-11740 | ELBOW | 1002-1100 | |
| 3 | 07831-00813 | SLEEVE | 1101- | |
| 3 | \0\281-35-19430 | SLEEVE | 1002-1100 | |
| 4 | 07832-00817 | NUT | 1101- | |
| 4 | \0\281-35-19930 | NUT | 1002-1100 | |
| 411-44-11440 | ELBOW | 1002- | ||
| 5 | 285-35-11680 | ELBOW | 1002- | |
| 6 | 281-35-19430 | SLEEVE | 1002- | |
| 7 | 281-35-19930 | NUT | 1002- | |
| 8 | 07822-00652 | TUBE | 1002- | |
| 281-35-19380 | CONNECTOR | 1002- | ||
| 9 | 07836-00613 | CONNECTOR | 1101- | |
| 9 | \0\281-35-19830 | NIPPLE | 1002-1100 | |
| 10 | 07831-00612 | SLEEVE | 1101- | |
| 10 | \0\281-35-19420 | SLEEVE | 1002-1100 | |
| 11 | 07832-00614 | NUT | 1101- | |
| 11 | \0\281-35-19920 | NUT | 1002-1100 | |
| 281-35-19340 | ELBOW | 1002- | ||
| 12 | 07834-00613 | ELBOW | 1101- | |
| 12 | \0\281-35-19880 | ELBOW | 1002-1100 | |
| 13 | 07831-00612 | SLEEVE | 1101- | |
| 13 | \0\281-35-19420 | SLEEVE | 1002-1100 | |
| 14 | 07832-00614 | NUT | 1101- | |
| 14 | \0\281-35-19920 | NUT | 1002-1100 | |
| 15 | (565-44-11201) | VALVE ASS'Y,(SEE FIG.347) | 1002- | |
| 16 | 01010-30825 | BOLT | 1002- | |
| 17 | 01602-00825 | WASHER,SPRING | 1002- | |
| 18 | 07822-00805 | TUBE | 1002- | |
| 19 | 07101-20408 | HOSE | 1002- | |
| 20 | 567-35-12120 | ELBOW | 1215- | |
| 20 | 567-35-12120 | ELBOW | 1002-1214 | |
| 20A | 07326-10302 | ADAPTER | 1215- | |
| 21 | 567-35-12180 | NIPPLE | 1002- | |
| 22 | (565-44-11502) | CHAMBER ASS'Y | 1002- | |
| 23 | 07822-00447 | TUBE | 1002- | |
| 281-35-19370 | CONNECTOR | 1002- | ||
| 24 | 07836-00413 | CONNECTOR | 1101- | |
| 24 | \0\281-35-19820 | CONNECTOR | 1002-1100 | |
| 25 | 07831-00411 | SLEEVE | 1101- | |
| 25 | \0\281-35-19410 | SLEEVE | 1002-1100 | |
| 26 | 07832-00410 | NUT | 1101- | |
| 26 | \0\281-35-19910 | NUT | 1002-1100 | |
| 281-35-19320 | ELBOW | 1002- | ||
| 27 | 07834-00413 | ELBOW | 1101- | |
| 27 | \0\281-35-19870 | ELBOW | 1002-1100 | |
| 28 | 07831-00411 | SLEEVE | 1101- | |
| 28 | \0\281-35-19410 | SLEEVE | 1002-1100 | |
| 29 | 07832-00410 | NUT | 1101- | |
| 29 | \0\281-35-19910 | NUT | 1002-1100 | |
| 30 | 07326-10302 | ADAPTER | 1002- | |
| 31 | 281-34-12501 | VALVE ASS'Y,RELEASE | 1002- | |
| 32 | 07042-20312 | PLUG | 1002- | |
| 33 | 01010-30820 | BOLT | 1002- | |
| 34 | 01602-00825 | WASHER | 1002- | |
| 35 | 07101-20408 | HOSE | 1002- | |
| 36 | 567-35-12120 | ELBOW | 1002- | |
| 37 | 567-35-12180 | NIPPLE | 1002- | |
| 38 | 560-44-14460 | NIPPLE | 1002- | |
| 39 | 08036-02514 | CLIP | 1002- | |
| 40 | 08036-03014 | CLIP | 1002- | |
| 41 | 01010-31020 | BOLT | 1002- | |
| 42 | 01602-01030 | WASHER | 1002- |
