| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 567-35-71132 | TUBE | 1601-@ | |
| 2 | 6166-91-6170 | JOINT | 1601-@ | |
| 3 | 6137-81-3140 | BOLT | 1601-@ | |
| 4 | 6164-91-6220 | GASKET | 1601-@ | |
| 5 | 567-35-71320 | BRACKET | 1601-@ | |
| 6 | 01435-01020 | BOLT | 1601-@ | |
| 7 | 07282-11568 | CLAMP | 1601-@ | |
| 8 | 01435-00816 | BOLT | 1601-@ | |
| 9 | 567-35-71330 | BRACKET | 1601-@ | |
| 10 | 01435-01020 | BOLT | 1601-@ | |
| 11 | 07282-11568 | CLAMP | 1601-@ | |
| 12 | 01435-00816 | BOLT | 1601-@ | |
| 13 | 07102-20409 | HOSE | 1601-@ | |
| 14 | 566-06-41290 | INSULATOR | 1001-@ | |
| 15 | 08036-03014 | CLIP | 1001-@ | |
| 16 | 01435-01020 | BOLT | 1201-@ | |
| 17 | 07004-01525 | GASKET | 1001-@ | |
| 18 | 431-35-11420 | CONNECTOR | 1001-@ | |
| 19 | 07834-00413 | ELBOW | 1001-@ | |
| 20 | 07831-00411 | SLEEVE | 1001-@ | |
| 21 | 07832-00410 | NUT | 1001-@ |
