| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07834-00817 | ELBOW | 1036- | |
| 1 | 07831-00813 | SLEEVE | 1036- | |
| 1 | 07832-00817 | NUT | 1036- | |
| 1 | 281-35-19350 | ELBOW,(SEE FIG.731) | 1011-1035 | |
| 2 | 07822-00803 | TUBE | 1036- | |
| 2 | \0\281-35-15771 | TUBE | 1011-1035 | |
| 3 | 08037-03614 | GROMMET | 1011- | |
| 4 | 07836-00817 | CONNECTOR | 1036- | |
| 4 | 07831-00813 | SLEEVE | 1036- | |
| 4 | 07832-00817 | NUT | 1036- | |
| 4 | 281-35-19390 | CONNECTOR,(SEE FIG.731) | 1011-1035 | |
| 5 | 411-44-15530 | JOINT | 1011- | |
| 6 | 411-44-15160 | JOINT | 1011- | |
| 6 | 566-44-14780 | RING | 1011- | |
| 7 | 411-44-14810 | PIPE | 1011- | |
| 8 | 411-44-15230 | ELBOW | 1011- | |
| 8 | 565-44-14780 | RING | 1011- | |
| 9 | 565-44-11100 | VALVE ASS'Y,BRAKE | 1011- | |
| 10 | 01010-50820 | BOLT | 1011- | |
| 11 | 01602-20825 | WASHER | 1011- | |
| 12 | 01580-10806 | NUT | 1011- | |
| 13 | 411-44-15230 | ELBOW | 1011- | |
| 13 | 565-44-14780 | RING | 1011- | |
| 14 | 411-44-14830 | PIPE | 1011- | |
| 15 | 411-44-15230 | ELBOW | 1011- | |
| 15 | 565-44-14780 | RING | 1011- | |
| 16 | 411-44-15230 | ELBOW | 1011- | |
| 16 | 565-44-14780 | RING | 1011- | |
| 17 | 411-44-14840 | PIPE | 1011- | |
| 18 | 411-44-15230 | ELBOW | 1011- | |
| 18 | 565-44-14780 | RING | 1011- | |
| 19 | 281-34-12300 | VALVE ASS'Y | 1011- | |
| 20 | 411-44-11180 | CLIP | 1011- | |
| 21 | 01580-10605 | NUT | 1011- | |
| 22 | 01602-20619 | WASHER | 1011- | |
| 23 | 411-44-15910 | BRACKET | 1011- | |
| 24 | 01010-51025 | BOLT | 1011- | |
| 25 | 01602-21030 | WASHER | 1011- | |
| 26 | 01580-11008 | NUT | 1011- | |
| 27 | 07834-00817 | ELBOW | 1036- | |
| 27 | 07831-00813 | SLEEVE | 1036- | |
| 27 | 07832-00817 | NUT | 1036- | |
| 27 | 281-35-19350 | ELBOW,(SEE FIG.731) | 1011-1035 | |
| 28 | 07834-00817 | ELBOW | 1036- | |
| 28 | 07831-00813 | SLEEVE | 1036- | |
| 28 | 07832-00817 | NUT | 1036- | |
| 28 | 281-35-19350 | ELBOW | 1011-1035 | |
| 29 | 07822-00802 | TUBE | 1036- | |
| 29 | \0\411-44-13432 | TUBE | 1011-1035 | |
| 30 | 07836-00817 | CONNECTOR | 1036- | |
| 30 | 07831-00813 | SLEEVE | 1036- | |
| 30 | 07832-00817 | NUT | 1036- | |
| 30 | 281-35-19390 | CONNECTOR | 1011-1035 | |
| 31 | 411-44-15530 | JOINT | 1011- | |
| 32 | 411-44-15160 | JOINT | 1011- | |
| 32 | 565-44-14780 | RING | 1011- | |
| 33 | 411-44-14820 | PIPE | 1011- | |
| 34 | 411-44-15230 | ELBOW | 1011- | |
| 34 | 565-44-14780 | RING | 1011- | |
| 35 | 411-44-15230 | ELBOW | 1011- | |
| 35 | 565-44-14780 | RING | 1011- | |
| 36 | 411-44-14850 | PIPE | 1011- | |
| 37 | 411-44-15230 | ELBOW | 1011- | |
| 37 | 565-44-14780 | RING | 1011- | |
| 38 | 411-44-15230 | ELBOW | 1011- | |
| 38 | 565-44-14780 | RING | 1011- | |
| 39 | 411-44-14861 | PIPE | 1011- | |
| 40 | 411-44-15230 | ELBOW | 1011- | |
| 40 | 565-44-14780 | RING | 1011- | |
| 41 | 281-34-12300 | VALVE ASS'Y | 1011- | |
| 42 | 07834-00817 | ELBOW | 1036- | |
| 42 | 07831-00813 | SLEEVE | 1036- | |
| 42 | 07832-00817 | NUT | 1036- | |
| 42 | 281-35-19350 | ELBOW,(SEE FIG.731) | 1011-1035 | |
| 43 | 07822-00805 | TUBE | 1036- | |
| 43 | \0\411-44-13132 | TUBE | 1011-1035 | |
| 44 | 411-44-11440 | ELBOW,(SEE FIG.731) | 1011- | |
| 45 | 411-44-15540 | JOINT | 1011- | |
| 46 | 07042-20211 | PLUG | 1011- | |
| 47 | 01010-51025 | BOLT | 1011- | |
| 48 | 01602-21030 | WASHER | 1011- | |
| 49 | 566-35-14210 | NIPPLE | 1011- | |
| 50 | 411-44-14880 | HOSE ASS'Y | 1011- | |
| 51 | 566-35-14210 | NIPPLE | 1011- | |
| 52 | 07836-00617 | CONNECTOR | 1036- | |
| 52 | 07831-00612 | SLEEVE | 1036- | |
| 52 | 07832-00614 | NUT | 1036- | |
| 52 | 281-35-19290 | CONNECTOR,(SEE FIG.731) | 1011-1035 | |
| 53 | 07822-00610 | TUBE | 1036- | |
| 53 | \0\411-44-13112 | TUBE | 1011-1035 | |
| 54 | 08036-01814 | CLIP | 1011- | |
| 55 | 01010-51016 | BOLT | 1011- | |
| 56 | 01602-21030 | WASHER | 1011- | |
| 57 | 07836-00613 | CONNECTOR | 1036- | |
| 57 | 07831-00612 | SLEEVE | 1036- | |
| 57 | 07832-00614 | NUT | 1036- | |
| 57 | 281-35-19380 | CONNECTOR,(SEE FIG.731) | 1011-1035 | |
| 58 | 411-44-11501 | VALVE ASS'Y,PARKING | 1011- | |
| 59 | 07834-00613 | ELBOW | 1036- | |
| 59 | 07831-00612 | SLEEVE | 1036- | |
| 59 | 07832-00614 | NUT | 1036- | |
| 59 | 281-35-19340 | ELBOW,(SEE FIG.731) | 1011-1035 | |
| 60 | 07822-00618 | TUBE | 1036- | |
| 60 | \0\411-44-13183 | TUBE | 1011-1035 | |
| 61 | 08034-00834 | BAND | 1036- | |
| 61 | \0\281-06-16760 | BAND | 1011-1035 | |
| 62 | 07834-00613 | ELBOW | 1036- | |
| 62 | 07831-00612 | SLEEVE | 1036- | |
| 62 | 07832-00614 | NUT | 1036- | |
| 62 | 281-35-19340 | ELBOW,(SEE FIG.731) | 1011-1035 | |
| 63 | 281-35-13120 | NIPPLE | 1011- | |
| 64 | 411-44-14890 | HOSE ASS'Y | 1011- | |
| 65 | 281-35-13120 | NIPPLE | 1011- |
