| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | VJ1025 | PRESSURE ARM | ||
| 2 | VJ1026 | SPRING | ||
| 3 | VS8323 | FLAT WASHER (BRASS) | ||
| 4 | VJ7853 | PIN, SPRING DOWEL | ||
| 5 | VS7587 | CAPSCREW W/WASHER - 1/4" - 20NC X 1/2" | ||
| 6 | VE4625 | CAPSCREW - 5/16" - 18NC X 1 1/4" | ||
| 7 | VE4626 | NUT |
- Главная
- Каталог запчастей
- Самосвалы
- Afe39 u 445e s/n a511001 a511044 (beml)
- Alternator group
- Alternator 25e1 3
Поиск по каталогу
ALTERNATOR - 25E1 - 3
