| Item | Part No. | Part Name | Qty | Serial No. |
| 707-00-50511 | CYLINDER ASS'Y | 10001-@ | ||
| 1 | 707-11-50141 | CYLINDER | 10001-@ | |
| 2 | 707-58-30250 | ROD,PISTON | 10001-@ | |
| 3 | 707-29-50330 | HEAD,CYLINDER | 10001-@ | |
| 4 | 707-36-50080 | PISTON | 10001-@ | |
| 5 | 07144-10302 | BUSHING | 10001-@ | |
| 6 | 07145-00030 | SEAL,DUST (KIT) | 10001-@ | |
| 7 | 07000-12060 | O-RING (KIT) | 10001-@ | |
| 8 | 07001-02060 | RING,BACK-UP (KIT) | 10001-@ | |
| 9 | 707-51-30030 | PACKING,ROD (KIT) | 10001-@ | |
| 10 | 07177-03025 | BUSHING | 10001-@ | |
| 11 | 707-56-30510 | SEAL,DUST (KIT) | 10001-@ | |
| 12 | 07179-12042 | RING,SNAP | 10001-11000 | |
| 13 | 707-45-50010 | WASHER,LOCK | 10001-@ | |
| 14 | 707-44-50180 | RING,PISTON (KIT) | 10001-@ | |
| 15 | 07155-00515 | RING,WEAR (KIT) | 10001-@ | |
| 16 | 07165-12222 | NUT,NYLON | 10001-@ | |
| 17 | 707-40-50080 | RETAINER | 10001-@ | |
| SERVICE KIT | ||||
| K | 707-99-04400 | SERVICE KIT,ANGLE CYLINDER | 10001-@ |
