| Item | Part No. | Part Name | Qty | Serial No. |
| 154-93-00072 | RAKE DOZER ASS'Y | 15677- | ||
| 154-93-00071 | RAKE DOZER ASS'Y | 11213-15676 | ||
| 154-93-00070 | RAKE DOZER ASS'Y | 10001-11212 | ||
| 154-93-00050 | FRAME ASS'Y | 10001- | ||
| 1 | 154-93-13320 | FRAME | 10001- | |
| 2 | 150-93-11137 | TEETH | 10001- | |
| 3 | 150-93-11140 | SHIM, 1.0MM | 10001- | |
| 4 | 150-93-11150 | BOLT | 10001- | |
| 4 | 01602-02783 | WASHER | 10001- | |
| 4 | 01580-02722 | NUT | 10001- | |
| 154-93-00061 | ARM ASS'Y | 15677- | ||
| 154-93-00060 | ARM ASS'Y | 11213-15676 | ||
| 154-93-00069 | ARM ASS'Y | 10001-11212 | ||
| 5 | 154-93-13330 | ARM | 10001- | |
| 154-70-00214 | CAP ASS'Y | 10001- | ||
| 6 | 175-70-12150 | BRACKET | 10001- | |
| 7 | 175-70-12160 | CAP | 10001- | |
| 8 | 01010-32095 | BOLT | 10001- | |
| 01602-02060 | WASHER | 10001- | ||
| 9 | 175-70-12130 | SCREW | 10001- | |
| 10 | 01010-31880 | BOLT | 10001- | |
| 10 | 01602-01854 | WASHER | 10001- | |
| 10 | 01580-01815 | NUT | 10001- | |
| 11 | 154-70-12162 | SHAFT | 15677- | |
| 11 | 154-70-12161 | SHAFT | 11213-15676 | |
| 11 | 154-70-12160 | SHAFT | 10001-11212 | |
| 12 | 154-70-12172 | PIN | 10001- | |
| 12 | 150-70-13420 | CHAIN (WELDED) | 10001- | |
| 13 | 175-70-12120 | BOSS (WELDED) | 10001- | |
| 14 | 154-70-12190 | BRACKET (WELDED) | 10001- | |
| 154-70-00084 | BRACE ASS'Y | 10001- | ||
| 15 | 154-70-12222 | BRACE | 10001- | |
| 16 | 150-70-12232 | BRACKET | 10001- | |
| 17 | 01010-32050 | BOLT | 10001- | |
| 18 | 01602-02060 | WASHER | 10001- | |
| 19 | 07020-00000 | FITTING | 10001- | |
| 20 | 175-70-12221 | SCREW | 10001- | |
| 21 | 01602-01442 | WASHER | 10001- | |
| 22 | 154-70-12251 | SCREW | 10001- | |
| 150-70-00198 | HOLDER ASS'Y | 10001- | ||
| 23 | 150-70-11411 | HOLDER | 10001- | |
| 24 | 150-70-11421 | SHAFT | 10001- | |
| 24 | 170-70-12280 | WASHER | 10001- | |
| 24 | 01593-04225 | NUT | 10001- | |
| 24 | 04050-08065 | PIN | 10001- | |
| 150-70-00185 | PIN ASS'Y | 10001- | ||
| 25 | 150-70-13410 | PIN | 10001- | |
| 26 | 170-70-12240 | PIN | 10001- | |
| 27 | 04050-04025 | PIN | 10001- |
