| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-52-83110 | BRACKET | 7001- | |
| 2 | 01010-81275 | BOLT | 7001- | |
| 3 | 01643-31232 | WASHER | 7001- | |
| 4 | 07042-70108 | PLUG | 7001- | |
| 5 | 07020-00000 | FITTING | 7001- | |
| 6 | 569-52-63120 | BRACKET | 7001- | |
| 7 | 07020-00000 | FITTING | 7001- | |
| 8 | 01010-81275 | BOLT | 7001- | |
| 9 | 01643-31232 | WASHER | 7001- | |
| 10 | 569-95-64310 | HOSE | 7001- | |
| 11 | 569-95-64330 | HOSE | 7001- | |
| 12 | 581-22-12660 | NIPPLE | 7001- | |
| 13 | 581-52-12410 | ELBOW | 7001- | |
| 14 | 08210-00605 | SPIRAL TUBE | 7001- | |
| 15 | 08210-00607 | SPIRAL TUBE | 7001- | |
| 16 | 569-95-64310 | HOSE | 7001- | |
| 17 | 581-22-12660 | NIPPLE | 7001- | |
| 18 | 569-95-64360 | HOSE | 7001- | |
| 19 | 569-95-64350 | HOSE | 7001- | |
| 20 | 581-22-12660 | NIPPLE | 7001- | |
| 21 | 581-52-12410 | ELBOW | 7001- | |
| 22 | 07323-30100 | ELBOW | 7001- | |
| 23 | 569-95-64370 | HOSE | 7001- | |
| 24 | 581-22-12660 | NIPPLE | 7001- | |
| 25 | 581-52-12410 | ELBOW | 7001- | |
| 26 | 562-95-13150 | NIPPLE | 7001- | |
| 27 | 08210-00607 | SPIRAL TUBE | 7001- | |
| 28 | 569-95-64360 | HOSE | 7001- | |
| 29 | 569-95-64350 | HOSE | 7001- | |
| 30 | 581-22-12660 | NIPPLE | 7001- | |
| 31 | 581-52-12410 | ELBOW | 7001- | |
| 32 | 569-95-64350 | HOSE | 7001- | |
| 33 | 581-52-12410 | ELBOW | 7001- | |
| 34 | 562-95-13150 | NIPPLE | 7001- | |
| 35 | 08210-00608 | SPIRAL TUBE | 7001- | |
| 36 | 569-95-64360 | HOSE | 7001- | |
| 37 | 569-95-64350 | HOSE | 7001- | |
| 38 | 581-22-12660 | NIPPLE | 7001- | |
| 39 | 581-52-12410 | ELBOW | 7001- | |
| 40 | 08210-00612 | SPIRAL TUBE | 7001- | |
| 41 | 04434-51812 | CLIP | 7001- | |
| 42 | 04434-50810 | CLIP | 7001- | |
| 43 | 01435-01016 | BOLT | 7001- | |
| 44 | 08210-01212 | SPIRAL TUBE | 7001- | |
| 45 | 08210-01206 | SPIRAL TUBE | 7001- | |
| 46 | 08034-00414 | BAND | 7001- | |
| 47 | 08034-00519 | BAND | 7001- |
