| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | HA0478 | HOSE | | |
| 2 | WB0403 | FITTING, UNION | | |
| 3 | HA0622 | HOSE (TO REAR INJECTORS) | | |
| 4 | TC1565 | CLAMP | | |
| 5 | VH9969 | WELD STUD - 3/8" - 16NC X 3/4" | | |
| 6 | C0312 | LOCKWASHER - 3/8" | | |
| 7 | C1521 | NUT - 3/8" - 16NC | | |
| 8 | WA2265 | HOSE | | |
| 9 | VA2636 | PUMP, GREASE | | |
| 10 | PB6410 | INDICATOR, LEVEL | | |
| 11 | WB0257 | FITTING, ELBOW - 90 DEG | | |
| 12 | C1604 | CAPSCREW - 3/8" - 16NC X 1 1/2" | | |
| 13 | TB3802 | RING | | |
| 14 | HA5229 | HOSE | | |
| 15 | C1605 | CAPSCREW - 3/8" - 16NC X 1 3/4" | | |
| 16 | TA4410 | INJECTOR | | |
| 17 | WB0262 | FITTING, ELBOW - 90 DEG | | |
| 18 | VW7990 | PROTECTOR, CAP | | |
| 19 | C5770 | PLUG, PIPE | | |
| 20 | WB0252 | FITTING, ELBOW - 90 DEG | | |
| 21 | WB0268 | FITTING, ELBOW - 90 DEG | | |
| 22 | SP4856 | ADAPTOR | | |
| 23 | WB0469 | ADAPTOR, STRAIGHT | | |
| 24 | TA1237 | PLATE, MANIFOLD | | |
| 25 | HA0398 | HOSE | | |
| 26 | HA5075 | HOSE | | |
| 27 | WB0375 | FITTING, ELBOW - 90 DEG | | |
| 28 | WB0362 | ADAPTOR, STRAIGHT | | |
| 29 | HA0640 | HOSE | | |
| 30 | WB0331 | TEE | | |
| 31 | TY8227 | WIRE | | |
| 32 | TY9712 | RING | | |
| 33 | TD9748 | ELBOW - 90 DEG | | |
| 34 | HA0392 | HOSE | | |
| 35 | TD9721 | FITTING | | |
| 36 | VW5013 | BRACKET | | |
| 37 | C1611 | CAPSCREW - 1/2" - 13NC X 3/4" | | |
| 38 | C1540 | LOCKWASHER - 1/2" | | |
| 39 | C5771 | PLUG, PIPE | | |
| 40 | PB2979 | MANIFOLD ASSM | | |
| 40 | VJ8272 | REGULATOR, AIR | | |
| 40 | VJ8306 | BRACKET, MOUNTING | | |
| 40 | TV9171 | GAUGE, AIR PRESSURE | | |
| 41 | C3145 | CAPSCREW - 1/4" - 20NC X 5/8" | | |
| 42 | C5774 | LOCKWASHER - 1/4" | | |
| 43 | VN9773 | FLAT WASHER - 1/4" | | |
| 44 | TA1236 | PIPE, BENT | | |
| 45 | TY9711 | NIPPLE, PIPE | | |
| 46 | PB6448 | VALVE, SOLENOID - SALEM | | |
| 47 | WB0258 | FITTING, ELBOW - 90 DEG | | |
| 48 | VZ0598 | TYRAP | | |
| 49 | WA2722 | FITTING | | |
