| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 421-06-42172 | WIRING HARNESS | A47001-- | |
| 2 | 01640-20610 | WASHER | A47001-- | |
| 3 | 04434-52712 | CLIP | A47001-- | |
| 4 | 07095-20418 | CUSHION | A47001-- | |
| 5 | 01010-81020 | BOLT | A47001-- | |
| 6 | 01643-31032 | WASHER | A47001-- | |
| 7 | 600-051-2180 | CLIP | A47001-- | |
| 8 | 01010-81025 | BOLT | A47001-- | |
| 9 | 01643-31032 | WASHER | A47001-- | |
| 10 | 01010-81025 | BOLT | A47001-- | |
| 11 | 01643-31032 | WASHER | A47001-- | |
| 12 | 04434-52712 | CLIP | A47001-- | |
| 13 | 07095-20418 | CUSHION | A47001-- | |
| 14 | 01010-81025 | BOLT | A47001-- | |
| 15 | 01643-31032 | WASHER | A47001-- | |
| 16 | 600-051-2240 | CLIP | A47001-- | |
| 17 | 01010-81025 | BOLT | A47001-- | |
| 18 | 01643-31032 | WASHER | A47001-- | |
| 19 | 600-051-2180 | CLIP | A47001-- | |
| 20 | 01010-81025 | BOLT | A47001-- | |
| 21 | 01643-31032 | WASHER | A47001-- | |
| 22 | 01010-81020 | BOLT | A47001-- | |
| 23 | 01643-31032 | WASHER | A47001-- | |
| 24 | 01580-11008 | NUT | A47001-- |
