| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07822-00830 | TUBE | 10581- | |
| 2 | 04434-53211 | CLIP | 10581- | |
| 3 | 01010-81020 | BOLT | 10581- | |
| 4 | 01643-31032 | WASHER | 10581- | |
| 5 | 04434-52711 | CLIP | 10581- | |
| 6 | 01010-81020 | BOLT | 10581- | |
| 7 | 01643-31032 | WASHER | 10581- |
- Главная
- Каталог запчастей
- Самосвалы
- Hd605 7e0 s/n 8001 10731 (ecot3)
- Electrical system
- Battery (air cleaner) (2/2) (sand protection)(#10581 )
Поиск по каталогу
BATTERY (AIR CLEANER) (2/2) (SAND PROTECTION)(#10581-)
