| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56B-06-27140 | Wiring Harness | 2848- | |
| 2 | 01010-81016 | Bolt | 2848- | |
| 3 | 01643-31032 | Washer | 2848- | |
| 4 | 04434-51010 | Clip | 2848- | |
| 5 | (56B-07-22775) | Bracket | - | |
| (56B-07-22774) | Bracket | - |
- Главная
- Каталог запчастей
- Самосвалы
- Hm400 2 s/n 2848 up (for kal)
- Electrical system
- Battery and battery case group, wiring harness (2/2) (#2848 )
Поиск по каталогу
Battery and Battery Case Group, Wiring Harness (2/2) (#2848-)
