| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-88-88670 | HOOD | 8001- | |
| 2 | 09450-00000 | CATCH | 8001- | |
| 3 | 09450-00002 | PIN | 8001- | |
| 4 | 04050-11610 | PIN | 8001- | |
| 5 | 569-54-81260 | SEAL | 8001- | |
| 6 | 569-54-88291 | SEAL | 8001- | |
| 7 | 09415-02512 | CAP | 8001- |
- Главная
- Каталог запчастей
- Самосвалы
- Hd605 7e0 s/n 8001 10731 (ecot3)
- Electrical system
- Battery (rear hood) (battery isolator)(#8001 )
Поиск по каталогу
BATTERY (REAR HOOD) (BATTERY ISOLATOR)(#8001-)
