| Item | Part No. | Part Name | Qty | Serial No. |
| 6245-81-6902 | TENSION ASS'Y | 511702- | ||
| 1 | 6245-81-6912 | BRACKET | 511702- | |
| 2 | 6162-64-3910 | BEARING | 511702- | |
| 3 | 6245-81-6840 | RACE,INNER | 511702- | |
| 4 | 6162-64-3930 | SEAL,DUST | 511702- | |
| 5 | 6245-81-6941 | SHAFT | 511702- | |
| 6 | 6245-81-6950 | SPRING,TENSION | 511702- | |
| 7 | 6245-81-6961 | PLATE | 511702- | |
| 8 | 01010-81020 | BOLT | 511702- | |
| 9 | 01643-31032 | WASHER | 511702- | |
| 10 | 04022-12035 | PIN,DOWEL | 511702- | |
| 11 | 6245-81-6971 | SHAFT | 511702- | |
| 12 | 06301-06306 | BEARING,BALL | 511702- | |
| 13 | 6245-81-6981 | SPACER | 511702- | |
| 14 | 6245-81-6990 | PLATE | 511702- | |
| 15 | 6245-81-6820 | PULLEY,TENSION | 511702- | |
| 16 | 6245-81-6830 | PLATE | 511702- | |
| 17 | 01435-01020 | BOLT | 511702- | |
| 18 | 07043-00108 | PLUG | 511702- | |
| 19 | 07029-00000 | VALVE,RELIEF | 511702- | |
| 20 | 01010-81090 | BOLT | 511702- | |
| 21 | 01010-81030 | BOLT | 511702- | |
| 22 | 01643-31032 | WASHER | 511702- | |
| 23 | 6245-81-6790 | BLOCK | 511702- | |
| 24 | 6245-81-6290 | BLOCK | 511702- | |
| 25 | 01010-81020 | BOLT | 511702- | |
| 26 | 01643-31032 | WASHER | 511702- | |
| 27 | 6245-81-6561 | BRACKET | 511702- | |
| 28 | 01010-81025 | BOLT | 511702- | |
| 29 | 01643-31032 | WASHER | 511702- | |
| 30 | 01010-81030 | BOLT | 511702- | |
| 31 | 01643-31032 | WASHER | 511702- | |
| 32 | 6934-71-5830 | BRACKET | 511702- | |
| 33 | 426-01-11310 | BRACKET | 511702- | |
| 34 | 01010-81040 | BOLT | 511702- | |
| 35 | 01643-31032 | WASHER | 511702- | |
| 36 | 426-06-11570 | BRACKET | 511702- | |
| 37 | 08193-20010 | CLIP | 511702- | |
| 38 | 01010-81025 | BOLT | 511702- | |
| 39 | 01643-31032 | WASHER | 511702- | |
| 40 | 01584-01008 | NUT | 511702- | |
| 41 | 6245-81-6890 | BRACKET | 511702- | |
| 42 | 01010-81025 | BOLT | 511702- | |
| 43 | 01643-31032 | WASHER | 511702- | |
| 44 | 01011-81000 | BOLT | 511702- | |
| 45 | 01643-31032 | WASHER | 511702- | |
| 46 | 6217-11-9770 | BRACKET | 511702- | |
| 47 | 6127-92-1250 | SPACER | 511702- | |
| 48 | 01010-81040 | BOLT | 511702- | |
| 49 | 01643-31032 | WASHER | 511702- | |
| 50 | 01010-81025 | BOLT | 511702- | |
| 51 | 01643-31032 | WASHER | 511702- | |
| 6245-81-6880 | COVER | 511702- | ||
| 52 | \6\ | COVER | 511702- | |
| 53 | 01026-A1025 | BOLT | 511702- | |
| 54 | 17M-911-6330 | GROMMET | 511702- |
