| Item | Part No. | Part Name | Qty | Serial No. |
| 201-63-02070 | CYLINDER ASS'Y,L.H. | 7501- | ||
| 201-63-02080 | CYLINDER ASS'Y,R.H. | 7501- | ||
| 1 | 201-63-92140 | CYLINDER,L.H. | 7501- | |
| 1 | 201-63-92240 | CYLINDER,R.H. | 7501- | |
| 2 | 07144-10506 | BUSHING | 7501- | |
| 3 | 07145-00055 | SEAL,DUST | 7501- | |
| 4 | 07020-00000 | FITTING,GREASE | 7501- | |
| 5 | 707-29-10391 | HEAD,CYLINDER | 7501- | |
| 6 | 07177-06030 | BUSHING | 7501- | |
| 7 | 707-51-60211 | PACKING,ROD | 7501- | |
| 8 | 141-63-93270 | SEAL,DUST | 7501- | |
| 9 | 07179-00082 | RING,SNAP | 7501- | |
| 10 | 07000-12105 | O-RING | 7501- | |
| 11 | 101-63-81230 | RING,BACK-UP | 7501- | |
| 12 | 201-63-92120 | ROD,PISTON | 7501- | |
| 13 | 07020-00675 | FITTING,GREASE | 7501- | |
| 14 | 707-36-10281 | PISTON | 7501- | |
| 15 | 07155-01025 | RING,WEAR | 7501- | |
| 16 | 707-44-10080 | RING,PISTON | 7501- | |
| 17 | 07165-14547 | NUT | 7501- | |
| 18 | 20S-62-11310 | ELBOW | 7501- | |
| 19 | 07002-12434 | O-RING | 7501- |
