| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 22B-70-19241 | BRACKET | 7793- | |
| 1 | 22B-70-19240 | BRACKET | 4501-7792 | |
| 2 | 22B-70-19131 | CLAMP | 7793- | |
| 2 | 22B-70-19130 | CLAMP | 4501-7792 | |
| 3 | 01010-81080 | BOLT | 4501- | |
| 4 | 01643-31032 | WASHER | 4501- | |
| 5 | 22B-70-19231 | BRACKET | 7793- | |
| 5 | 22B-70-19230 | BRACKET | 4501-7792 | |
| 6 | 22B-70-19130 | CLAMP | 4501- | |
| 7 | 01010-81085 | BOLT | 4501- | |
| 8 | 01643-31032 | WASHER | 4501- | |
| 9 | 22B-70-19221 | BRACKET | 7793- | |
| 9 | 22B-70-19220 | BRACKET | 4501-7792 | |
| 10 | 01010-81040 | BOLT | 4501- | |
| 11 | 01643-31032 | WASHER | 4501- | |
| 12 | 22B-70-19111 | CLAMP | 7793- | |
| 12 | 22B-70-19110 | CLAMP | 4501-7792 | |
| 13 | 01010-81030 | BOLT | 4501- | |
| 14 | 01643-31032 | WASHER | 4501- | |
| 15 | 22B-70-19211 | BRACKET | 7793- | |
| 15 | 22B-70-19210 | BRACKET | 4501-7792 | |
| 16 | 01010-81040 | BOLT | 4501- | |
| 17 | 01643-31032 | WASHER | 4501- | |
| 18 | 22B-70-19141 | CLAMP | 7793- | |
| 18 | 22B-70-19140 | CLAMP | 4501-7792 | |
| 19 | 01010-81085 | BOLT | 4501- | |
| 20 | 01643-31032 | WASHER | 4501- | |
| 21 | 21K-62-35270 | CUSHION | 4501- | |
| 22 | 203-70-61251 | TUBE | 4501- | |
| 23 | 203-70-61261 | TUBE | 4501- | |
| 24 | 203-70-61271 | TUBE | 4501- | |
| 25 | 203-70-61281 | TUBE | 4501- | |
| 26 | 203-70-61291 | TUBE | 4501- | |
| 27 | 07020-00900 | FITTING | 4501- | |
| 28 | 20Y-70-11540 | CONNECTOR | 4501- | |
| 29 | 20Y-70-11590 | ELBOW | 4501- | |
| 30 | 04435-50810 | CLIP | 4501- | |
| 31 | 04434-51712 | CLIP | 4501- | |
| 32 | 08036-00814 | CLIP | 4501- | |
| 33 | 01010-81020 | BOLT | 4501- | |
| 34 | 01643-31032 | WASHER | 4501- | |
| 35 | 205-70-51390 | NIPPLE | 4501- | |
| 36 | 20Y-70-11520 | HOSE, 440MM | 4501- | |
| 37 | 20Y-25-11270 | ELBOW | 4501- |
