| Item | Part No. | Part Name | Qty | Serial No. |
| 102-33-00014 | BRAKE BAND ASS'Y | 30540- | ||
| \0\102-33-00013 | BRAKE BAND ASS'Y | 30277-30539 | ||
| \0\102-33-00012 | BRAKE BAND ASS'Y | .-30276 | ||
| \0\102-33-00011 | BRAKE BAND ASS'Y | 28877-. | ||
| \0\102-33-00010 | BRAKE BAND ASS'Y | 20007-28876 | ||
| 1 | \6\ | BAND,BRAKE | 30540- | |
| 1 | \6\ | BAND,BRAKE | 30277-30539 | |
| 1 | \6\ | BAND,BRAKE | .-30276 | |
| 1 | \6\ | BAND,BRAKE | 28877-. | |
| 1 | \6\ | BAND,BRAKE | 20007-28876 | |
| 2 | 101-33-11240 | END,BRAKE BAND | 20007-30276 | |
| 3 | 04400-00522 | RIVET | 20007-30276 | |
| 4 | 101-33-21280 | LINING,BRAKE | 30540- | |
| 4 | 101-33-21280 | LINING,BRAKE | 30277-30539 | |
| 4 | \6\ | LINING,BRAKE | .-30276 | |
| 4 | \6\ | LINING,BRAKE | 20007-. | |
| 4A | 101-33-21271 | LINING,BRAKE | 30277-30539 | |
| 4A | \6\ | LINING,BRAKE | .-30276 | |
| 5 | 101-33-21290 | LINING,BRAKE | 30277- | |
| 5 | \6\ | LINING,BRAKE | 20007-30276 | |
| 6 | 04412-00512 | RIVET | 30540- | |
| 6 | 04412-00510 | RIVET | 30277-30539 | |
| 6 | 04412-00409 | RIVET | 20007-30276 | |
| 7 | 101-33-21221 | SPRING | 30277- | |
| 7 | 101-33-21220 | SPRING | 28877-30276 | |
| 7 | 101-33-11370 | SPRING | 20339-28876 | |
| 8 | 04400-00512 | RIVET | 30540- | |
| 8 | 04400-00510 | RIVET | 30277-30539 | |
| 8 | 04400-00412 | RIVET | 20007-30276 | |
| 9 | 100-33-13190 | SPRING | 20007- | |
| 10 | 100-33-13180 | BOLT | 20007- | |
| 11 | 01580-00806 | NUT | 20007- | |
| 12 | 101-33-11361 | LEVER,L.H. | .- | |
| 12 | 101-33-11360 | LEVER,L.H. | 20007-. | |
| 12 | 101-33-11261 | LEVER,R.H. | .- | |
| 12 | 101-33-11260 | LEVER,R.H. | 20007-. | |
| 13 | 101-33-11280 | SHAFT | 20007- | |
| 14 | 101-33-11310 | BOLT | 20007- | |
| 15 | 101-33-21110 | NUT | 20007- | |
| 16 | 101-33-11290 | ANCHOR,BRAKE BAND | 20007- | |
| 17 | 01010-31230 | BOLT | 20007- | |
| 18 | 01602-01236 | WASHER,SPRING | 20007- | |
| 19 | 101-33-21160 | ROD,BRAKE, L.H. | .- | |
| 19 | \0\04248-11043 | ROD,BRAKE, L.H. | 20007-. | |
| 19 | 101-33-21170 | ROD,BRAKE, R.H. | .- | |
| 19 | \0\04248-11036 | ROD,BRAKE, R.H. | 20007-. | |
| 20 | 04220-21040 | YOKE,L.H. THREAD | .- | |
| 20 | 101-33-11351 | YOKE,L.H. THREAD | 20007-. | |
| 21 | 01508-11006 | NUT, L.H. THREAD,L.H. THREAD | 20007- | |
| 22 | 04205-11030 | PIN | .- | |
| 22 | 04205-11028 | PIN | 20007-. | |
| 23 | 01641-21016 | WASHER | .- | |
| 24 | 101-33-21260 | PIN,COTTER | .- | |
| 24 | \0\04050-03015 | PIN,COTTER | 20007-. | |
| 25 | 100-33-13190 | SPRING | 30277- | |
| 25 | 101-33-21250 | SPRING | .-30276 | |
| 25 | 101-33-11270 | SPRING | 20007-. | |
| 26 | 04211-01055 | YOKE | 20007- | |
| 27 | 01583-01006 | NUT | 20007- | |
| 28 | 04205-01026 | PIN | 20007- | |
| 29 | 101-33-21260 | PIN,COTTER | .- | |
| 29 | \0\04050-03015 | PIN,COTTER | 20007-. | |
| 30 | 101-40-11440 | BELLOWS | 20007- | |
| 31 | 101-40-11282 | COVER | 20007- | |
| 32 | 01010-30812 | BOLT | 20007- | |
| 33 | 01602-00825 | WASHER,SPRING | 20007- |
