| Item | Part No. | Part Name | Qty | Serial No. |
| 113-33-43114 | BAND ASS'Y,BRAKE | 46677- | ||
| \0\113-33-43113 | BAND ASS'Y,BRAKE | 45825-46676 | ||
| \0\113-33-43112 | BAND ASS'Y,BRAKE | 45001-45824 | ||
| 1 | \6\ | BAND | 45001- | |
| 113-33-05014 | SERVICE KIT | 46677- | ||
| \0\113-33-05013 | SERVICE KIT | 45825-46676 | ||
| \0\113-33-05012 | SERVICE KIT | 45001-45824 | ||
| 2 | \6\ | LINING (K2) | 46677- | |
| 2 | \6\ | LINING (K2) | 45825-46676 | |
| 2 | \6\ | LINING (K2) | 45001-45824 | |
| 3 | \6\ | LINING (K2) | 46677- | |
| 3 | \6\ | LINING (K2) | 45825-46676 | |
| 3 | \6\ | LINING (K2) | 45001-45824 | |
| 4 | \6\ | LINING (K2) | 46677- | |
| 4 | \6\ | LINING (K2) | 45825-46676 | |
| 4 | \6\ | LINING (K2) | 45001-45824 | |
| 5 | \6\ | LINING (K2) | 45001-46676 | |
| 6 | \6\ | LINING (K2) | 46677- | |
| 6 | \6\ | LINING (K2) | 45825-46676 | |
| 6 | \6\ | LINING (K2) | 45001-45824 | |
| 7 | \6\ | LINING (K2) | 45001-46676 | |
| 8 | \6\ | LINING (K2) | 46677- | |
| 8 | \6\ | LINING (K2) | 45001-46676 | |
| 9 | \6\ | LINING (K2) | 45825-46676 | |
| 9 | \6\ | LINING (K2) | 45001-45824 | |
| 10 | 04412-00514 | RIVET | 45001- | |
| 11 | 04412-00519 | RIVET | 45001- | |
| 12 | 113-33-32170 | ANCHOR | 45001- | |
| 13 | 113-33-22180 | PIN | 45001- | |
| 14 | 01010-81435 | BOLT | 45001- | |
| 15 | 01602-21442 | WASHER,SPRING | 45001- | |
| 16 | 113-33-32240 | LEVER | 45001- | |
| 17 | 113-33-32180 | PIN | 45001- | |
| 18 | 113-33-32210 | ROD | 45001- | |
| 19 | 113-33-32230 | PIN | 45001- | |
| 20 | 01641-21626 | WASHER | 45001- | |
| 21 | 04050-14025 | PIN,COTTER | 45001- | |
| 22 | 113-33-32220 | NUT | 45001- | |
| 23 | 120-33-32221 | END | 45001- | |
| 24 | 113-33-32190 | PIN | 45001- | |
| 25 | 131-33-41461 | SPRING | 45001- |
