| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56B-03-21502 | OIL COOLER | 2001- | |
| 2 | 01010-81030 | BOLT | 2001- | |
| 3 | 01643-31032 | WASHER | 2001- | |
| 4 | 207-62-64740 | O-RING | 2001- | |
| 5 | 56B-03-21511 | TUBE | 2001- | |
| 6 | 209-62-55281 | FLANGE | 2001- | |
| 7 | 01010-81245 | BOLT | 2001- | |
| 8 | 01643-51232 | WASHER | 2001- | |
| 9 | 07000-F2060 | O-RING | 2001- | |
| 10 | 56B-03-21520 | HOSE | 2001- | |
| 11 | 07299-00070 | CLAMP | 2001- | |
| 12 | 56B-03-21790 | CLAMP | 2001- | |
| 13 | 01010-81020 | BOLT | 2001- | |
| 14 | 01643-31032 | WASHER | 2001- | |
| 15 | 09482-20000 | VALVE | 2001- | |
| 16 | 11Y-09-11140 | CLIP | 2001- | |
| 17 | 07270-01535 | TUBE | 2001- |
