| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 566-35-42950 | CONNECTOR | 2001-@ | |
| 2 | 07103-50324 | HOSE | 2001-2263 | |
| 3 | 566-35-42830 | TUBE | 2001-2263 | |
| 4 | 07217-51013 | ELBOW | 2001-@ | |
| 5 | 566-35-11360 | JOINT | 2001-@ | |
| 6 | 566-35-42761 | TUBE | 2001-2263 | |
| 7 | 07214-51013 | CONNECTOR | 2001-@ | |
| 8 | 566-35-11360 | JOINT | 2001-@ | |
| 9 | 566-35-42840 | TUBE | 2001-2263 | |
| 10 | 07103-50318 | HOSE | 2001-2263 | |
| 11 | 566-35-14360 | NIPPLE | 2001-@ | |
| 12 | 08036-02514 | CLIP | 2001-@ | |
| 13 | 01010-51020 | BOLT | 2001-@ | |
| 14 | 01602-21030 | WASHER,SPRING | 2001-2263 | |
| 15 | 07283-21022 | CLIP | 2001-@ | |
| 16 | 01598-00608 | NUT | 2001-@ | |
| 17 | 01643-30623 | WASHER | 2001-@ |
