| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 566-43-83753 | PLATE | 7001- | |
| 2 | 566-43-83850 | BRACKET | 7001- | |
| 3 | 01010-81030 | BOLT | 7001- | |
| 4 | 01643-31032 | WASHER | 7001- | |
| 5 | 01010-81035 | BOLT | 7001- | |
| 6 | 01643-31032 | WASHER | 7001- | |
| 7 | 566-43-83610 | CLAMP | 7001- | |
| 8 | 561-43-83211 | PLATE | 7001- | |
| 9 | 561-43-83221 | PLATE | 7001- | |
| 10 | 01010-81280 | BOLT | 7001- | |
| 11 | 01643-31232 | WASHER | 7001- | |
| 12 | 04434-53212 | CLIP | 7001- | |
| 13 | 07095-20523 | CUSHION | 7001- | |
| 14 | 01010-81025 | BOLT | 7001- | |
| 15 | 01643-31032 | WASHER | 7001- | |
| 16 | 56B-61-14230 | BRACKET | 7001- | |
| 17 | 04434-53412 | CLIP | 7001- | |
| 18 | 07095-20627 | CUSHION | 7001- | |
| 19 | 02765-004A4 | HOSE | 7001- | |
| 20 | 02766-004A3 | HOSE | 7001- | |
| 21 | 566-43-85262 | TUBE | 7001- | |
| 22 | 02896-21015 | O-RING | 7001- | |
| 23 | 566-44-83361 | PLATE | 7001- | |
| 24 | 566-44-83372 | PLATE | 7001- | |
| 25 | 01010-81025 | BOLT | 7001- | |
| 26 | 01643-31032 | WASHER | 7001- | |
| 27 | 07283-32236 | CLIP | 7001- | |
| 28 | 01597-01009 | NUT | 7001- | |
| 29 | 01643-31032 | WASHER | 7001- | |
| 30 | 04434-52110 | CLIP | 7001- | |
| 31 | 01010-81020 | BOLT | 7001- | |
| 32 | 01643-31032 | WASHER | 7001- | |
| 33 | 04434-52712 | CLIP | 7001- | |
| 34 | 07095-20420 | CUSHION | 7001- | |
| 35 | 01010-81020 | BOLT | 7001- | |
| 36 | 01643-31032 | WASHER | 7001- | |
| 41 | 566-88-81160 | PLATE | 7001- | |
| 42 | 01010-81025 | BOLT | 7001- | |
| 43 | 01643-31032 | WASHER | 7001- | |
| 44 | 07283-32236 | CLIP | 7001- | |
| 45 | 01597-01009 | NUT | 7001- | |
| 46 | 01643-31032 | WASHER | 7001- |
