| Item | Part No. | Part Name | Qty | Serial No. |
| 120-Y46-0040 | C-FRAME ASS'Y | 6009- | ||
| 120-Y46-0080 | C-FRAME ASS'Y | 6001-6008 | ||
| 1 | \6\ | C-FRAME | 6009- | |
| 1 | \6\ | C-FRAME | 6001-6008 | |
| 2 | 120-Y46-3221 | BRACKET | 6001- | |
| 3 | 120-Y46-3231 | BRACKET | 6001- | |
| 3 | 120-Y46-3241 | BRACKET | 6001- | |
| 4 | 120-Y46-3252 | BRACKET | 6001- | |
| 4 | 120-Y46-3262 | BRACKET | 6001- | |
| 5 | 120-Y46-3271 | BEARING | 6001- | |
| 6 | 130-70-13140 | PIVOT | 6001- | |
| 7 | 120-Y46-3281 | CAP | 6001- | |
| 8 | 01011-62445 | BOLT | 6001- | |
| 9 | 01643-32460 | WASHER | 6001- | |
| 10 | 130-70-13241 | NUT | 6001- | |
| 11 | 120-Y46-3291 | CAP | 6001- | |
| 12 | 01010-52490 | BOLT | 6001- | |
| 13 | 01643-32460 | WASHER | 6001- | |
| 14 | 120-Y46-3411 | TRUNNION | 6001- | |
| 15 | 01010-52055 | BOLT | 6001- | |
| 16 | 01643-32060 | WASHER | 6001- | |
| 17 | 130-817-5461 | SHAFT | 6001- | |
| 18 | 124-Z46-1260 | PIN | 6001- | |
| 19 | 01010-51080 | BOLT | 6001- | |
| 20 | 01010-51095 | BOLT | 6001- | |
| 21 | 01598-11011 | NUT | 6001- | |
| 22 | 09241-50180 | PIN | 6001- | |
| 23 | 09241-50210 | PIN | 6001- | |
| 24 | 124-Z46-1330 | BUSHING | 6001- | |
| 25 | 124-Z46-1340 | COLLAR | 6001- | |
| 26 | 04082-00212 | LOCK | 6001- | |
| 27 | 01010-51225 | BOLT | 6001- | |
| 28 | 01602-21236 | WASHER,SPRING | 6001- | |
| 29 | 07020-00000 | FITTING,GREASE | 6001- | |
| 30 | 124-Z46-1320 | BEARING | 6001- | |
| 31 | 04065-08025 | RING,SNAP | 6001- | |
| SERVICE PARTS | ||||
| 1 | 120-Y46-0050 | PIVOT ASS'Y | 6001- | |
| 6 | \6\ | PIVOT | 6001- | |
| 7 | 120-Y46-3281 | CAP | 6001- | |
| 8 | 01011-62445 | BOLT | 6001- | |
| 9 | 01643-32460 | WASHER | 6001- | |
| 10 | 130-70-13241 | NUT | 6001- | |
| SERVICE PARTS | ||||
| 1 | 120-Y46-0070 | PIVOT ASS'Y | 6001- | |
| 5 | \6\ | BEARING | 6001- | |
| 11 | 120-Y46-3291 | CAP | 6001- | |
| 12 | 01010-52490 | BOLT | 6001- | |
| 13 | 01643-32460 | WASHER | 6001- |
