| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 421-03-31181 | TANK, RADIATOR RESERVOIR | A41001-- | |
| 2 | 421-03-41610 | BRACKET | A41001-- | |
| 3 | 01010-81025 | BOLT | A41001-- | |
| 4 | 01643-31032 | WASHER | A41001-- | |
| 5 | 424-03-41440 | BRACKET | A41001-- | |
| 6 | 01010-80820 | BOLT | A41001-- | |
| 7 | 01643-30823 | WASHER | A41001-- | |
| 8 | 208-03-58290 | HOSE | A41001-- | |
| 9 | 04434-51212 | CLIP | A41001-- | |
| 10 | 01010-81020 | BOLT | A41001-- | |
| 11 | 01643-31032 | WASHER | A41001-- | |
| 12 | 424-03-41433 | HOSE | A41001-- | |
| 13 | 206-03-43340 | CLIP | A41001-- | |
| 14 | 04434-51212 | CLIP | A41001-- | |
| 15 | 01010-81020 | BOLT | A41001-- | |
| 16 | 01643-31032 | WASHER | A41001-- | |
| 17 | 04434-51712 | CLIP | A41001-- | |
| 18 | 01010-81020 | BOLT | A41001-- | |
| 19 | 01643-31032 | WASHER | A41001-- | |
| 20 | 134-03-61410 | BAND | A41001-- | |
| 21 | 04434-51212 | CLIP | A41001-- |
