| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 12Y-03-13463 | HOSE, FAN SUPPLY | B10001- | |
| 2 | 07002-12034 | O-RING | B10001- | |
| 3 | 02781-00422 | UNION | B10001- | |
| 4 | 02896-11012 | O-RING | B10001- | |
| 5 | 07094-10417 | CLAMP, HOSE | B10001- | |
| 6 | 01010-81265 | BOLT, MOUNT CLAMP | B10001- | |
| 01643-31232 | WASHER | B10001- | ||
| 7 | 07095-00419 | CUSHION | B10001- | |
| 8 | 12Y-03-13541 | CLAMP, HOSE | B10001- | |
| 9 | 01010-81225 | BOLT, MOUNT CLAMP | B10001- | |
| 01643-31232 | WASHER | B10001- |
