| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 09482-20000 | VALVE | 1001- | |
| 2 | 561-07-63260 | JOINT | 1001- | |
| 3 | 09483-40428 | HOSE | 1001- | |
| 4 | 07280-02323 | CLAMP | 1001- | |
| 5 | 08036-02514 | CLIP | 1001- | |
| 6 | 09483-40422 | HOSE | 1001- | |
| 7 | 565-04-11420 | TUBE,SPIRAL | 1001- | |
| 8 | 08034-00519 | BAND | 1001- | |
| 9 | 01010-51020 | BOLT | 1001- | |
| 10 | 01643-31032 | WASHER | 1001- | |
| 11 | 569-07-61541 | CLAMP | 1054- | |
| 12 | 569-07-61551 | CLAMP | 1054- | |
| 13 | 01010-81045 | BOLT | .- | |
| \0\01010-51045 | BOLT | 1001-. | ||
| 14 | 01643-31032 | WASHER | 1054- | |
| 15 | 561-07-63211 | PLATE | 1054- | |
| 16 | 561-07-45120 | ELBOW | 1001- | |
| 17 | 569-07-62550 | CLAMP | 1054- |
