| Item | Part No. | Part Name | Qty | Serial No. |
| 565-07-15012 | CAR HEATER ASS'Y | 1424- | ||
| 565-07-15011 | CAR HEATER ASS'Y | 935-1423 | ||
| 565-07-15010 | CAR HEATER ASS'Y | 510-934 | ||
| 1 | 566-07-15110 | CAR HEATER ASS'Y | 510- | |
| 566-07-15500 | LEVER ASS'Y | 510- | ||
| 2 | 566-07-15510 | PANEL ASS'Y | 510- | |
| 3 | 566-07-15530 | KNOB | 510- | |
| 4 | 566-07-15560 | SWITCH | 510- | |
| 5 | 566-07-15580 | BRACKET | 510- | |
| 6 | 566-07-15590 | LEVER | 510- | |
| 7 | 566-07-15610 | LEVER | 510- | |
| 8 | 566-07-15620 | PIN | 510- | |
| 9 | 566-07-15630 | WASHER | 510- | |
| 10 | 566-07-15640 | SPRING | 510- | |
| 11 | 566-07-15650 | RING | 510- | |
| 12 | 566-07-15660 | CLIP | 510- | |
| 13 | 566-07-15670 | SCREW | 510- | |
| 14 | 566-07-15680 | WASHER | 510- | |
| 15 | 566-07-15690 | SCREW | 510- | |
| 16 | 566-07-15710 | SCREW | 510- | |
| 17 | 566-07-15110 | CAR HEATER ASS'Y | 510- | |
| 18 | 565-07-15120 | HARNESS | 510- | |
| 19 | 566-07-15570 | WIRING HARNESS | 510- | |
| 20 | 567-07-15221 | NIPPLE | 1124- | |
| 20 | 567-07-15221 | NIPPLE | .-1123 | |
| 20 | \0\567-07-15220 | VALVE | 510-. | |
| 21 | 09483-00517 | HOSE | 726- | |
| 22 | 09483-00528 | HOSE | 1424- | |
| 22 | 09483-00525 | HOSE | 726-1423 | |
| 23 | 565-95-17230 | CLAMP | 1148- | |
| 23 | 565-95-17230 | CLAMP | 510-1147 | |
| 24 | 565-07-15130 | HOSE | 510-934 | |
| 24A | 566-07-15240 | HOSE | 935- | |
| 25 | 565-95-17280 | PIPE | 510-934 | |
| 26 | 565-95-17260 | HOSE | 510-934 | |
| 27 | 565-07-15140 | HOSE | 510-934 | |
| 28 | 565-07-15150 | HOSE | 510-934 | |
| 29 | 565-95-17290 | CLIP | 510-934 | |
| 29A | 565-07-15170 | CLIP | 935- | |
| 565-07-15160 | CONNECTOR | 510-1423 | ||
| 30 | 565-07-15161 | JOINT | 1424- | |
| 31 | 565-07-15180 | HOSE | 1148- | |
| 32 | 09484-00550 | CONNECTOR | 1148- | |
| 33 | 566-07-15210 | BRACKET | 510- | |
| 34 | 01010-31020 | BOLT | 510- | |
| 35 | 01602-01030 | WASHER | 510- | |
| 36 | 01010-30820 | BOLT | 510- | |
| 37 | 01602-00825 | WASHER | 510- | |
| 38 | 04434-00608 | CLIP | 510- | |
| 39 | 08036-02514 | CLIP | 726- | |
| 40 | 01010-30816 | BOLT | 935- | |
| 40 | 01010-30816 | BOLT | 510-934 | |
| 41 | 01602-00825 | WASHER | 935- | |
| 41 | 01602-00825 | WASHER | 510-934 | |
| 42 | 08037-02512 | GROMMET | 510- | |
| 43 | 01580-00605 | NUT | 510- | |
| 44 | 01602-00619 | WASHER | 510- | |
| 45 | 565-82-11130 | BUSHING | 1424- |
