| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | PB8946 | PANEL, STATEX III (SEE INDEX) | ||
| 2 | MM0460 | FLAT WASHER - M8 | ||
| 3 | MM0470 | LOCKWASHER - M8 | ||
| 4 | MM0177 | NUT - M8 | ||
| 5 | EF5554 | TRANSFORMER, SYNC | ||
| 6 | MM0459 | FLAT WASHER - M6 | ||
| 7 | MM0378 | LOCKWASHER - M4 | ||
| 8 | MM0372 | NUT - M4 | ||
| 9 | PB7591 | BLOCK, TERMINAL | ||
| 10 | VS0035 | LIGHT, DOME | ||
| 10 | VZ1912 | BULB | ||
| 10 | TM9090 | INSULATOR | ||
| 11 | DC3101 | LOCKWASHER - #10 | ||
| 12 | TG1929 | MACHINE SCREW - #10 | ||
| 13 | PB5587 | MODULE, CONTROL POWER DIODE | ||
| 14 | SD5369 | MACHINE SCREW | ||
| 15 | VC5344 | FLAT WASHER - #10 | ||
| 16 | VG7043 | RELAY (SEE INDEX) | ||
| 17 | MM0469 | LOCKWASHER - M6 | ||
| 18 | MM0176 | NUT - M6 | ||
| 19 | DL9148 | BAR, BUS | ||
| 20 | WA3367 | NUT ASSEMBLY | ||
| 21 | PB4255 | MODULE, SUPPRESSION | ||
| 22 | DF0017 | NUT | ||
| 23 | SD4245 | LOCKWASHER - #10 | ||
| 24 | EC7259 | PLATE, NAME - CPD2 | ||
| 25 | EC7258 | PLATE, NAME - CPD1 | ||
| 26 | TZ7542 | PLATE, NAME - GB3 | ||
| 27 | EC7461 | PLATE, NAME - DL6 | ||
| 28 | WB2077 | DECAL, DIAGNOSTIC PANEL | ||
| 29 | EC7256 | PLATE, NAME - ST2 | ||
| 30 | TZ7521 | PLATE, NAME - PLCP | ||
| 31 | MM0206 | LOCKWASHER - M5 | ||
| 32 | MM0373 | NUT - M5 | ||
| 33 | VS8479 | BOARD, TERMINAL | ||
| 34 | PB5732 | BOARD, TERMINAL | ||
| 35 | ED6897 | PLATE, NAME - TB21J | ||
| 36 | EB7403 | PLATE, NAME - TB21H | ||
| 37 | EC7252 | PLATE, NAME - CNE | ||
| 38 | EC7251 | PLATE, NAME - CND | ||
| 39 | EC2723 | PLATE, NAME - CNC | ||
| 40 | EC2722 | PLATE, NAME - CNB | ||
| 41 | EC2721 | PLATE, NAME - CNA | ||
| 42 | TZ7526 | PLATE, NAME - GFR | ||
| 43 | TZ7527 | PLATE, NAME - CPR | ||
| 44 | EC7255 | PLATE, NAME - ST1 | ||
| 45 | WB2819 | PLATE, NAME - LLDT | ||
| 46 | PB9972 | TIMER | ||
| 47 | EG2362 | RESISTOR | ||
| 48 | EG2363 | HOUSING |
