| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 09483-40316 | HOSE | 7006- | |
| \0\09483-40317 | HOSE | 7001-7005 | ||
| 2 | 08037-01610 | GROMMET | 7001- | |
| 3 | 6128-61-9530 | HOSE | 7006- | |
| \0\569-03-62412 | HOSE | 7001-7005 | ||
| 4 | 07281-10167 | CLAMP | 7001- | |
| 5 | 07281-10197 | CLAMP | 7001- | |
| 6 | 07270-40825 | TUBE | 7001- | |
| 7 | 07281-10137 | CLAMP | 7001- | |
| 8 | 08037-01610 | GROMMET | 7001- | |
| 9 | 04434-51610 | CLIP | 7001- | |
| 10 | 08036-01214 | CLIP | 7001- | |
| 11 | 01435-01014 | BOLT | 7001- | |
| 12 | 283-35-11120 | ADAPTER | 7001- | |
| 13 | 431-03-11310 | NIPPLE | 7001- | |
| 14 | 195-03-13241 | VALVE | 7001- | |
| 15 | 07270-41511 | TUBE | 7001- | |
| 16 | 07281-10197 | CLAMP | 7001- | |
| 17 | 08036-01814 | CLIP | 7001- | |
| 18 | 01435-01014 | BOLT | 7001- | |
| 19 | 569-03-82450 | HOSE | 7001- | |
| 20 | 07289-00045 | CLAMP | 7001- | |
| 21 | 206-979-4380 | CLIP | 7001- | |
| 22 | 01435-01014 | BOLT | 7001- | |
| 23 | 09483-40318 | HOSE | 7001- | |
| 24 | 431-03-11310 | NIPPLE | 7001- | |
| 25 | 07326-10201 | ADAPTER | 7001- | |
| 26 | 07281-10197 | CLAMP | 7001- | |
| 27 | 08036-01814 | CLIP | 7001- | |
| 28 | 01435-01014 | BOLT | 7001- | |
| 29 | 09483-40318 | HOSE | 7001- | |
| 30 | 08036-01814 | CLIP | 7001- | |
| 31 | 07281-10197 | CLAMP | 7001- | |
| 32 | 01435-01014 | BOLT | 7001- | |
| 33 | 427-43-11370 | BRACKET | 7001- | |
| 34 | 09483-40310 | HOSE | 7001- | |
| 35 | 07281-10197 | CLAMP | 7001- | |
| 36 | 08036-01814 | CLIP | 7001- | |
| 37 | 569-03-32130 | HOSE | 7001- | |
| 38 | 07299-00095 | CLAMP | 7001- |
