| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-03-62151 | HOSE | 7001- | |
| 2 | 07299-00105 | CLAMP | 7001- | |
| 3 | 569-03-82112 | TUBE | 7006- | |
| \0\569-03-82111 | TUBE | 7001-7005 | ||
| 4 | 07000-12100 | O-RING | 7001- | |
| 5 | 01010-81040 | BOLT | 7001- | |
| 6 | 01643-31032 | WASHER | 7001- | |
| 7 | 569-03-82350 | BRACKET | 7001- | |
| 8 | 01010-81290 | BOLT | 7001- | |
| 9 | 01010-81230 | BOLT | 7001- | |
| 10 | 01643-31232 | WASHER | 7001- | |
| 11 | 07283-38973 | CLIP | 7001- | |
| 12 | 01597-01211 | NUT | 7001- | |
| 13 | 01643-31232 | WASHER | 7001- | |
| 14 | 07283-37663 | CLIP | 7001- | |
| 15 | 01597-01009 | NUT | 7001- | |
| 16 | 01643-31032 | WASHER | 7001- | |
| 17 | 569-03-62230 | HOSE | 7001- | |
| 18 | 07289-00070 | CLAMP | 7001- | |
| 19 | 569-03-82360 | BRACKET | 7001- | |
| 20 | 07283-37663 | CLIP | 7001- | |
| 21 | 01597-01009 | NUT | 7001- | |
| 22 | 01643-31032 | WASHER | 7001- | |
| 23 | 569-03-82120 | TUBE | 7001- | |
| 24 | 07000-12075 | O-RING | 7001- | |
| 25 | 01010-81245 | BOLT | 7001- | |
| 26 | 01643-51232 | WASHER | 7001- | |
| 27 | 07260-27416 | HOSE | 7001- | |
| 28 | 07299-00095 | CLAMP | 7001- | |
| 29 | 569-03-82130 | TUBE | 7001- | |
| 30 | 07000-12075 | O-RING | 7001- | |
| 31 | 01010-81245 | BOLT | 7001- | |
| 32 | 01643-51232 | WASHER | 7001- | |
| 33 | 07260-27416 | HOSE | 7001- | |
| 34 | 07299-00095 | CLAMP | 7001- | |
| 35 | 569-03-82370 | BRACKET | 7001- | |
| 36 | 07283-37663 | CLIP | 7001- | |
| 37 | 01597-01009 | NUT | 7001- | |
| 38 | 01643-31032 | WASHER | 7001- | |
| 39 | 195-03-13241 | VALVE | 7001- | |
| 40 | 07270-01535 | TUBE | 7001- | |
| 41 | 07285-00155 | CLIP | 7001- |
