| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-03-88290 | NIPPLE | 10271- | |
| 2 | 07002-11823 | O-RING | 10271- | |
| 3 | 07283-37663 | CLIP | 10271- | |
| 4 | 01597-01009 | NUT | 10271- | |
| 5 | 01643-31032 | WASHER | 10271- | |
| 6 | 07283-37663 | CLIP | 10271- | |
| 7 | 01597-01009 | NUT | 10271- | |
| 8 | 01643-31032 | WASHER | 10271- | |
| 9 | 569-03-88122XC | TUBE | 10271- | |
| 10 | 07000-12075 | O-RING | 10271- | |
| 11 | 01010-81245 | BOLT | 10271- | |
| 11 | 01643-31232 | WASHER | 10271- | |
| 12 | 01010-81245 | BOLT | 10271- | |
| 13 | 01643-31232 | WASHER | 10271- | |
| 14 | 569-03-88131 | TUBE | 10271- | |
| 15 | 07000-12075 | O-RING | 10271- | |
| 16 | 01010-81250 | BOLT | 10271- | |
| 17 | 01643-31232 | WASHER | 10271- | |
| 18 | 569-03-82371 | BRACKET | 10271- | |
| 19 | 07283-37663 | CLIP | 10271- | |
| 20 | 01597-01009 | NUT | 10271- | |
| 21 | 01643-31032 | WASHER | 10271- |
