| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-03-8L381 | Tube | 30001- | |
| 2 | 569-03-8L391 | Bracket | 30001- | |
| 3 | 01010-81230 | Bolt | 30001- | |
| 4 | 01643-31232 | Washer | 30001- | |
| 5 | 07283-37671 | Clip | 30001- | |
| 6 | 01643-31032 | Washer | 30001- | |
| 7 | 22P-70-12160 | Nut | 30001- | |
| 8 | 569-03-8L420 | Hose | 30001- | |
| 9 | 07299-00095 | Clamp, Hose | 30001- |
