| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 21W-03-41210 | HOSE | 1001- | |
| 2 | 20Y-62-15960 | CLIP | 1001- | |
| 3 | 01010-81020 | BOLT | 1001- | |
| 4 | 01643-31032 | WASHER | 1001- | |
| 5 | 21W-03-41220 | HOSE | 1001- | |
| 6 | 07289-00045 | CLAMP | 1001- | |
| 7 | 07289-00055 | CLAMP | 1001- | |
| 8 | 01010-81030 | BOLT | 1001- | |
| 9 | 01643-31032 | WASHER | 1001- | |
| 10 | 21W-03-31510 | CUSHION | 1001- | |
| 11 | 01580-10806 | NUT | 1001- | |
| 12 | 01643-30823 | WASHER | 1001- | |
| 13 | 21W-03-42540 | BRACKET | 1190- | |
| 13 | 21W-03-41342 | BRACKET | 1001-1189 | |
| 14 | 175-61-23220 | WASHER | 1190- | |
| 15 | 01010-81025 | BOLT | 1001- | |
| 16 | 01643-31032 | WASHER | 1001- | |
| 17 | 21W-03-41350 | BRACKET | 1001- | |
| 18 | 01010-81020 | BOLT | 1001- | |
| 19 | 01643-31032 | WASHER | 1001- | |
| 20 | 21W-03-41780 | TANK ASS'Y | 1001- | |
| 21 | 417-03-21350 | CAP | 1001- | |
| 22 | 362-03-14120 | BRACKET | 1001- | |
| 23 | 01010-80616 | BOLT | 1001- | |
| 24 | 01643-30623 | WASHER | 1001- | |
| 25 | 21W-03-41181 | BRACKET | 1001- | |
| 26 | 01010-81025 | BOLT | 1001- | |
| 27 | 01643-31032 | WASHER | 1001- | |
| 28 | 08034-40521 | BAND | 1001- | |
| 29 | 21T-68-11320 | CLIP | 1001- | |
| 30 | 01010-81016 | BOLT | 1001- | |
| 31 | 01643-31032 | WASHER | 1001- | |
| 32 | 206-03-43340 | CLIP | 1001- | |
| 33 | 21W-03-41131 | HOSE | 1001- | |
| 34 | 21W-03-41711 | SHEET | 1001- | |
| 35 | 21W-03-41721 | SHEET | 1001- | |
| 36 | 21W-03-41730 | SHEET | 1001- | |
| 37 | 21W-03-41740 | SHEET | 1001- | |
| 38 | 21W-03-41750 | SHEET | 1001- |
