| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20Y-03-21810 | RADIATOR CORE ASS'Y | 10001-10021 | |
| 2 | 205-03-71280 | CAP ASS'Y | 10001-10021 | |
| 3 | 205-03-62660 | PLUG | 10001-@ | |
| 4 | 07000-01007 | O-RING | 10001-@ | |
| 5 | 363-03-11150 | TUBE | 10001-@ | |
| 6 | 20Y-03-11330 | CLIP | 10001-@ | |
| 7 | 22U-03-11121 | OIL COOLER ASS'Y | 10001-@ | |
| 8 | 20Y-03-11242 | SEAL | 10001-@ | |
| 9 | 01010-81225 | BOLT | 10001-@ | |
| 10 | 01643-31232 | WASHER | 10001-@ | |
| 11 | 22U-03-11140 | NET | 10001-@ | |
| 12 | 22U-03-11150 | NET | 10001-@ | |
| 13 | 20Y-03-11570 | SEAL | 10001-@ | |
| 14 | 01434-10616 | BOLT¤ WING | 10001-@ | |
| 15 | 01643-30823 | WASHER | 10001-@ | |
| 16 | 22U-03-11450 | SEAL | 10001-@ | |
| 17 | 22U-03-11131 | SHROUD | 10001-10021 | |
| 18 | 01435-20816 | BOLT | 10001-@ | |
| 19 | 20Y-03-14110 | SEAL | 10001-@ | |
| 20 | 22U-03-11421 | SHEET | 10001-@ | |
| 21 | 22U-03-11431 | SHEET | 10001-@ | |
| 22 | 22U-03-11441 | SHEET | 10001-@ | |
| 23 | 22U-03-11460 | SHEET | 10001-@ | |
| 24 | 22U-03-11470 | SHEET | 10001-@ | |
| 25 | 22U-03-11221 | HOSE | 10001-@ | |
| 26 | 07289-00055 | CLAMP | 10001-@ | |
| 27 | 22U-03-11210 | HOSE | 10001-@ | |
| 28 | 07289-00055 | CLAMP | 10001-@ | |
| 29 | 07289-00070 | CLAMP | 10001-@ | |
| 30 | 208-62-38370 | CLIP | 10001-@ | |
| 31 | 01010-81040 | BOLT | 10001-@ | |
| 32 | 01643-31032 | WASHER | 10001-@ | |
| 33 | 6631-11-5630 | SPACER | 10001-@ |
