| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 04435-50610 | Clip | 90023- | |
| 2 | 01010-81020 | Bolt | 90023- | |
| 3 | 01643-31032 | Washer | 90023- | |
| 4 | 423-03-31710 | Boss | 90023- | |
| 5 | 600-645-7850 | Fan | 90023- | |
| 6 | 01010-81030 | Bolt | 90023- | |
| 7 | 01643-31032 | Washer | 90023- | |
| 8 | 04010-00722 | Key | 90023- | |
| 9 | 01583-12012 | Nut | 90023- | |
| 10 | 154-03-72270 | Lock | 90023- | |
| 11 | 01010-81020 | Bolt | 90023- | |
| 12 | 01643-31032 | Washer | 90023- | |
| 13 | 14X-03-61310 | Bracket | 90023- | |
| 14 | 01010-81235 | Bolt | 90023- | |
| 15 | 01643-31232 | Washer | 90023- | |
| 16 | 421-09-31110 | Elbow | 90023- | |
| 17 | 02896-11015 | O-ring | 90023- | |
| 18 | 07002-12434 | O-ring | 90023- | |
| 19 | 423-62-52290 | Plug | 90638- | |
| 19 | 07040-11007 | Plug | 90023-90637 | |
| 20 | 07002-11023 | O-ring | 90023- | |
| 21 | 02781-00522 | Union | 90023- | |
| 22 | 07002-12434 | O-ring | 90023- | |
| 23 | 02896-11015 | O-ring | 90023- | |
| 24 | 02782-10420 | Elbow | 90023- | |
| 25 | 07002-11823 | O-ring | 90023- | |
| 26 | 02896-11012 | O-ring | 90023- | |
| 27 | 14X-03-51320 | Tube | 90023- | |
| 28 | 02896-11015 | O-ring | 90023- | |
| 29 | 14X-62-32540 | Clamp | 90023- | |
| 30 | 01010-81050 | Bolt | 90023- | |
| 31 | 01643-31032 | Washer | 90023- |
