| Item | Part No. | Part Name | Qty | Serial No. |
| CUAR-11177 | CRANKSHAFT ASS'Y | 576252- | ||
| 1 | CU204640 | CRANKSHAFT | 576252- | |
| 2 | CU204548 | GEAR,CRANKSHAFT | 576252- | |
| 3 | CU64490 | KEY | 576252- | |
| 4 | 02720-20204 | PLUG | 576252- | |
| STANDARD | ||||
| CUAR-4220 | MAIN METAL ASS'Y | 576252- | ||
| 5 | CU200520 | METAL,UPPER, NO.1 | 576252- | |
| 6 | CU200530 | METAL,LOWER, NO.1 | 576252- | |
| 7 | \6\ | METAL,UPPER, NO.2,3,5,6 | 576252- | |
| 8 | \6\ | METAL,LOWER, NO.2,3,5,6 | 576252- | |
| 9 | \6\ | METAL,UPPER, NO.4 | 576252- | |
| 10 | \6\ | METAL,LOWER, NO.4 | 576252- | |
| 11 | \6\ | METAL,UPPER, NO.7 | 576252- | |
| 12 | \6\ | METAL,LOWER, NO.7 | 576252- | |
| 13 | CU180280 | METAL,THRUST | 576252- | |
| UNDERSIZE 0.25MM | ||||
| 5 | CUAR-4221 | MAIN METAL ASS'Y | 576252- | |
| 5 | CU200520 | METAL,UPPER, NO.1 | 576252- | |
| 6 | CU200530 | METAL,LOWER, NO.1 | 576252- | |
| 7 | \6\ | METAL,UPPER, NO.2,3,5,6 | 576252- | |
| 8 | \6\ | METAL,LOWER, NO.2,3,5,6 | 576252- | |
| 9 | \6\ | METAL,UPPER, NO.4 | 576252- | |
| 10 | \6\ | METAL,LOWER, NO.4 | 576252- | |
| 11 | \6\ | METAL,UPPER, NO.7 | 576252- | |
| 12 | \6\ | METAL,LOWER, NO.7 | 576252- | |
| 13 | CU180280 | METAL,THRUST | 576252- | |
| UNDERSIZE 0.50MM | ||||
| 5 | CUAR-4222 | MAIN METAL ASS'Y | 576252- | |
| 5 | CU200520 | METAL,UPPER, NO.1 | 576252- | |
| 6 | CU200530 | METAL,LOWER, NO.1 | 576252- | |
| 7 | \6\ | METAL,UPPER, NO.2,3,5,6 | 576252- | |
| 8 | \6\ | METAL,LOWER, NO.2,3,5,6 | 576252- | |
| 9 | \6\ | METAL,UPPER, NO.4 | 576252- | |
| 10 | \6\ | METAL,LOWER, NO.4 | 576252- | |
| 11 | \6\ | METAL,UPPER, NO.7 | 576252- | |
| 12 | \6\ | METAL,LOWER, NO.7 | 576252- | |
| 13 | CU180280 | METAL,THRUST | 576252- | |
| UNDERSIZE 0.75MM | ||||
| 5 | CUAR-4223 | MAIN METAL ASS'Y | 576252- | |
| 5 | CU200520 | METAL,UPPER, NO.1 | 576252- | |
| 6 | CU200530 | METAL,LOWER, NO.1 | 576252- | |
| 7 | \6\ | METAL,UPPER, NO.2,3,5,6 | 576252- | |
| 8 | \6\ | METAL,LOWER, NO.2,3,5,6 | 576252- | |
| 9 | \6\ | METAL,UPPER, NO.4 | 576252- | |
| 10 | \6\ | METAL,LOWER, NO.4 | 576252- | |
| 11 | \6\ | METAL,UPPER, NO.7 | 576252- | |
| 12 | \6\ | METAL,LOWER, NO.7 | 576252- | |
| 13 | CU180280 | METAL,THRUST | 576252- | |
| 14 | 6610-21-1280 | PIN,DOWEL | 576252- | |
| 15 | 6715-31-1410 | PULLEY | 576252- | |
| 16 | CU193553 | DAMPER | 576252- | |
| 17 | CU213364 | BOLT | 576252- | |
| 18 | CU148916 | WASHER,SPRING | 576252- | |
| 19 | CU205679 | BOLT | 576252- | |
| 20 | CU140218 | WASHER | 576252- |
