| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 257-10-16100 | DASHBOARD | 1001-1200 | |
| 2 | 01010-31016 | BOLT | 1001-@ | |
| 3 | 01602-01030 | WASHER | 1001-@ | |
| 4 | 265-82-24050 | GROMMET | 1001-1200 | |
| 5 | 257-10-16700 | PANEL | 1001-@ | |
| 6 | 257-10-16800 | PIN | 1001-@ | |
| 7 | 257-30-15320 | SPRING | 1001-@ | |
| 8 | 266-60-44321 | PIN | 1001-@ | |
| 9 | 257-10-16910 | PIN | 1001-@ | |
| 10 | 257-10-16920 | SPACER | 1001-@ | |
| 11 | 266-96-30010 | KNOB | 1001-@ | |
| 12 | 01010-30835 | BOLT | 1001-@ | |
| 13 | 01602-00825 | WASHER | 1001-@ | |
| 14 | 01016-30830 | BOLT | 1001-@ | |
| 15 | 01580-00806 | NUT | 1001-@ | |
| 16 | 257-10-17630 | MIRROR | 1001-1200 | |
| 17 | 257-10-17620 | STAY | 1001-@ | |
| 18 | 01580-01210 | NUT | 1001-@ | |
| 19 | 01602-01236 | WASHER | 1001-@ | |
| 20 | 266-91-12000 | WASHER | 1001-1200 |
