| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 561-88-64120 | BOARD | 2001- | |
| 2 | 283-17-18710 | PEDAL | 2001- | |
| 3 | 283-17-18720 | SPRING | 2001- | |
| 4 | 283-17-18730 | PIN | 2001- | |
| 5 | 01641-20812 | WASHER | 2001- | |
| 6 | 04050-12015 | PIN | 2001- | |
| 7 | 01010-51035 | BOLT | 2001- | |
| 8 | 01580-11008 | NUT | 2001- | |
| 9 | 561-88-64140 | BRACKET | 2001- | |
| 10 | 01010-51020 | BOLT | 2001- | |
| 11 | 01643-31032 | WASHER | 2001- | |
| 12 | 566-06-41412 | SWITCH | 2001- | |
| 13 | 01010-50616 | BOLT | 2001- | |
| 14 | 01643-30623 | WASHER | 2001- | |
| 15 | 561-88-64550 | MAT | 2001- | |
| 16 | 561-88-64160 | WIRING HARNESS | 2001- | |
| 17 | 566-35-11520 | BOSS | 2001- | |
| 18 | 561-88-44180 | BRACKET | 2001- | |
| 19 | 01010-50825 | BOLT | 2001- | |
| 20 | 01643-30823 | WASHER | 2001- | |
| 21 | 283-95-14500 | VALVE | 2001- | |
| 22 | 01220-40512 | SCREW | 2001- | |
| 23 | 01641-20508 | WASHER | 2001- | |
| 24 | 561-88-64170 | WIRING HARNESS | 2001- | |
| 25 | 08052-11911 | CLIP | 2001- | |
| 26 | 08036-00614 | CLIP | 2001- | |
| 27 | 08034-00414 | BAND | 2001- | |
| 28 | 568-35-11420 | TEE | 2001- | |
| 29 | 07326-00402 | ADAPTER | 2001- | |
| 30 | 07822-00605 | TUBE | 2001- | |
| 31 | 07831-00612 | SLEEVE | 2001- | |
| 32 | 07832-00614 | NUT | 2001- | |
| 33 | 07834-00613 | ELBOW | 2001- | |
| 34 | 567-35-12160 | ELBOW | 2001- | |
| 35 | 07102-20210 | HOSE | 2001- | |
| 36 | 07238-00210 | CONNECTOR | 2001- | |
| 37 | 581-35-23540 | INSULATOR | 2001- | |
| 38 | 08036-02514 | CLIP | 2001- | |
| 39 | 01010-51020 | BOLT | 2001- | |
| 40 | 01580-11008 | NUT | 2001- | |
| 41 | 01643-31032 | WASHER | 2001- |
