| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07102-20304 | HOSE | 30417- | |
| 1 | 20U-62-23650 | HOSE, 400MM | 30001-30416 | |
| 2 | 20T-62-84430 | HOSE | 30001- | |
| 3 | (20T-62-84150) | HOSE,(SEE FIG. H1840-01A0-22) | 30001-31204 | |
| 4 | 04434-53211 | CLIP | 30001- | |
| 5 | 01010-81025 | BOLT | 30001- | |
| 6 | 01643-31032 | WASHER | 30001- | |
| 7 | 04434-51510 | CLIP | 30001- | |
| 8 | 203-62-41150 | COVER | 30001- | |
| 9 | 08034-00823 | BAND | 30001- | |
| 10 | 203-62-32440 | COVER | 30001- | |
| 11 | 21W-62-22930 | HOSE | 30417- |
