| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07102-20504 | HOSE | 80001-@ | |
| 2 | 07102-20513 | HOSE | 81311-94998 | |
| 2 | 07102-20512 | HOSE | 80001-81310 | |
| 3 | 08036-02514 | CLIP | 80001-94998 | |
| 4 | 01010-51225 | BOLT | 80001-94998 | |
| 5 | 01643-31232 | WASHER | 80001-94998 | |
| 6 | 198-61-14180 | CLIP | 88565-94998 | |
| 6 | 176-911-4180 | CLIP | 80001-88564 | |
| 7 | 01010-51230 | BOLT | 80001-94998 | |
| 8 | 01643-31232 | WASHER | 80001-94998 | |
| 9 | 07102-20606 | HOSE | 80001-94998 | |
| 10 | 07235-10628 | ELBOW | 80001-@ | |
| 11 | 07002-02434 | O-RING | 80001-@ |
